6N137的详细信息

Manufacturer: Vishay
Product Category: High Speed Optocouplers
RoHS: Yes
Brand: Vishay Semiconductors
Current Transfer Ratio: 1600 %
Data Rate: 10 MBd
Maximum Forward Diode Voltage: 1.7 V
Maximum Reverse Diode Voltage: 5 V
Maximum Power Dissipation: 85 mW
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 40 C
Package / Case: PDIP-8
Packaging: Tube
Fall Time: 7 ns
Forward Current: 20 mA
Input Type: AC/DC
Isolation Voltage: 5300 Vrms
Maximum Continuous Output Current: 50 mA
Maximum Forward Diode Current: 20 mA
Minimum Forward Diode Voltage: 1.1 V
Number of Channels per Chip: 1 Channel
Output Device: Photo IC
Rise Time: 23 ns
Factory Pack Quantity: 2000
6N137, VO2601, VO2611, VO2630, VO2631, VO4661
www.vishay.com
Vishay Semiconductors
High Speed Optocoupler, Single and Dual, 10 MBd
FEATURES
Single channel
• Choice of CMR performance of 15 kV/μs,
5 kV/μs, and 100 V/μs
NC
A
1
2
3
4
8
7
6
5
V
CC
V
E
• High speed: 10 MBd typical
• + 5 V CMOS compatibility
• Pure tin leads
V
C
O
NC
GND
• Guaranteed AC and DC performance over
temperature: - 40 °C to + 100 °C temperature range
6N137, VO2601, VO2611
Dual channel
• Meets IEC 60068-2-42 (SO2) and IEC 60068-2-43 (H2S)
requirements
1
2
3
4
8
7
6
5
A1
C1
C2
A2
V
CC
V
O1
• Low input current capability: 5 mA
V
• Material categorization: For definitions of compliance
please see www.vishay.com/doc?99912
O2
GND
VO2630, VO2631, VO4661
APPLICATIONS
18921-15
• Microprocessor system interface
• PLC, ATE input/output isolation
• Computer peripheral interface
• Digital fieldbus isolation: CC-link, DeviceNet, profibus, SDS
• High speed A/D and D/A conversion
• AC plasma display panel level shifting
• Multiplexed data transmission
• Digital control power supply
DESCRIPTION
The 6N137, VO2601, and VO2611 are single channel
10 MBd optocouplers utilizing a high efficient input LED
coupled with an integrated optical photodiode IC detector.
The detector has an open drain NMOS-transistor output,
providing less leakage compared to an open collector
Schottky clamped transistor output. The VO2630, VO2631,
and VO4661 are dual channel 10 MBd optocouplers. For the
single channel type, an enable function on pin 7 allows the
detector to be strobed. The internal shield provides a
guaranteed common mode transient immunity of 5 kV/μs for
the VO2601 and VO2631 and 15 kV/μs for the VO2611 and
VO4661. The use of a 0.1 μF bypass capacitor connected
between pin 5 and 8 is recommended.
• Ground loop elimination
AGENCY APPROVALS
• UL1577, file no. E52744 system code H, double protection
• cUL - file no. E52744, equivalent to CSA bulletin 5A
• DIN EN 60747-5-5 (VDE 0884-5) available with option 1
• BSI IEC 60950
• CQC GB8898-2001
ORDERING INFORMATION
DIP-8
Option 6
V
O
2
6
0
1
-
X
0
#
#
T
10.16 mm
7.62 mm
Option 7
PART NUMBER
PACKAGE OPTION
TAPE
AND
REEL
> 0.7 mm
CHANNELS 1
CMR (V/μs)
5000
CHANNELS 2
CMR (V/μs)
5000
AGENCY CERTIFIED/PACKAGE
BSI, UL, cUL
1000
15 000
1000
VO2630
15 000
DIP-8
6N137
VO2601
VO2611
VO2631
VO4661
DIP-8, 400 mil, option 6
SMD-8, option 7
VDE, BSI, UL, cUL
DIP-8, 400 mil, option 6
SMD-8, option 7
6N137-X006
VO2601-X006 VO2611-X006 VO2630-X006 VO2631-X006 VO4661-X006
6N137-X007T VO2601-X007T VO2611-X007T VO2630-X007T VO2631-X007T VO4661-X007T
1000
-
-
5000
15 000
1000
5000
15 000
VO2601-X016 VO2611-X016
VO2601-X017T VO2611-X017T
-
-
-
-
-
VO2631-X017T
Rev. 1.6, 25-Sep-12
Document Number: 84732
1
