型号: 74HC138D,653
厂商: NXP Semiconductors NXP Semiconductors
标准:
分类: 半导体集成电路 - IC
描述: encoders, decoders, multiplexers & Demultiplexers 3-OF-8 decoder/demux
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载2 >> 第三方平台下载 >>

74HC138D,653的详细信息

Manufacturer: NXP
Product Category: Encoders, Decoders, Multiplexers & Demultiplexers
RoHS: Yes
Brand: NXP Semiconductors
Logic Family: HC
Number of Input Lines: 3
Number of Output Lines: 8
Propagation Delay Time: 50 ns
Supply Voltage - Max: 6 V
Supply Voltage - Min: 2 V
Maximum Operating Temperature: + 125 C
Mounting Style: SMD/SMT
Package / Case: SOT-109
Packaging: Reel
Minimum Operating Temperature: - 40 C
Number of Lines In/Out: 3 / 8
Factory Pack Quantity: 2500
Part # Aliases: 74HC138D-T
74HC138; 74HCT138
3-to-8 line decoder/demultiplexer; inverting
Rev. 4 — 27 June 2012
Product data sheet
1. General description
The 74HC138; 74HCT138 is a high-speed Si-gate CMOS device and is pin compatible
with Low-power Schottky TTL (LSTTL).
The 74HC138; 74HCT138 decoder accepts three binary weighted address inputs (A0, A1
and A3) and when enabled, provides 8 mutually exclusive active LOW outputs (Y0 to Y7).
The 74HC138; 74HCT138 features three enable inputs: two active LOW (E1 and E2) and
one active HIGH (E3). Every output is HIGH unless E1 and E2 are LOW and E3 is HIGH.
This multiple enable function allows easy parallel expansion of the 74HC138; 74HCT138
to a 1-of-32 (5 lines to 32 lines) decoder with just four 74HC138; 74HCT138 ICs and one
inverter.
The 74HC138; 74HCT138 can be used as an eight output demultiplexer by using one of
the active LOW enable inputs as the data input and the remaining enable inputs as
strobes. Permanently tie unused enable inputs to their appropriate active HIGH- or
LOW-state.
The 74HC138; 74HCT138 is identical to the 74HC238; 74HCT238 but has inverting
outputs.
2. Features and benefits
Demultiplexing capability
Multiple input enable for easy expansion
Complies with JEDEC standard no. 7A
Ideal for memory chip select decoding
Active LOW mutually exclusive outputs
ESD protection:
HBM EIA/JESD22-A114F exceeds 2000 V
MM EIA/JESD22-A115-A exceeds 200 V
Multiple package options
Specified from 40 °C to +85 °C and from 40 °C to +125 °C
