型号: 74HC245D,653
厂商: NXP Semiconductors NXP Semiconductors
标准:
分类: 半导体集成电路 - IC
描述: bus transceivers octal transceiver 3-state
PDF: 预览
报错 收藏

74HC245D,653的详细信息

Manufacturer: NXP
Product Category: Bus Transceivers
RoHS: Yes
Brand: NXP Semiconductors
Logic Type: CMOS
Logic Family: HC
Number of Channels per Chip: 8
Input Level: CMOS
Output Level: CMOS
Output Type: 3-State
High Level Output Current: - 7.8 mA
Low Level Output Current: 7.8 mA
Propagation Delay Time: 90 ns
Supply Voltage - Max: 6 V
Supply Voltage - Min: 2 V
Maximum Operating Temperature: + 125 C
Package / Case: SO-20
Packaging: Reel
Function: Bus Transceiver
Minimum Operating Temperature: - 40 C
Mounting Style: SMD/SMT
Number of Circuits: 1
Polarity: Non-Inverting
Factory Pack Quantity: 2000
Part # Aliases: 74HC245D-T
74HC245; 74HCT245
Octal bus tranceiver; 3-state
Rev. 03 — 31 January 2005
Product data sheet
1. General description
The 74HC245; 74HCT245 is a high-speed Si-gate CMOS device and is pin compatible
with Low-Power Schottky TTL (LSTTL).
The 74HC245; 74HCT245 is an octal transceiver featuring non-inverting 3-state bus
compatible outputs in both send and receive directions. The 74HC245; 74HCT245
features an output enable input (OE) for easy cascading and a send/receive input (DIR)
for direction control. OE controls the outputs so that the buses are effectively isolated.
The 74HC245; 74HCT245 is similar to the 74HC640; 74HCT640 but has true
(non-inverting) outputs.
2. Features
Octal bidirectional bus interface
Non-inverting 3-state outputs
Multiple package options
Complies with JEDEC standard no. 7A
ESD protection:
HBM EIA/JESD22-A114-B exceeds 2000 V
MM EIA/JESD22-A115-A exceeds 200 V
Specified from 40 °C to +85 °C and from 40 °C to +125 °C
3. Quick reference data
Table 1:
Quick reference data
GND = 0 V; Tamb = 25 °C; tr = tf = 6 ns.
Symbol
Parameter
Conditions
Min
Typ
Max
Unit
Type 74HC245
tPHL, tPLH
propagation delay
CL = 15 pF;
-
7
-
ns
An to Bn or Bn to An
VCC = 5 V
CI
input capacitance
-
-
-
3.5
10
30
-
-
-
pF
pF
pF
CI/O
CPD
input/output capacitance
power dissipation
capacitance per
transceiver
VI = GND to VCC
Type 74HCT245
tPHL, tPLH propagation delay
An to Bn or Bn to An
CL = 15 pF;
CC = 5 V
-
10
-
ns
V
