74HC259N,652的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | Latches |
| RoHS： | Yes |
| Brand： | NXP Semiconductors |
| Number of Circuits： | 1 Circuit |
| Logic Type： | CMOS |
| Logic Family： | 74HC |
| Polarity： | Non-Inverting |
| Number of Output Lines： | 8 Line |
| High Level Output Current： | - 5.2 mA |
| Propagation Delay Time： | 185 ns at 2 V, 37 ns at 4.5 V, 31 ns at 6 V |
| Supply Voltage - Max： | 6 V |
| Supply Voltage - Min： | 2 V |
| Maximum Operating Temperature： | + 125 C |
| Minimum Operating Temperature： | - 40 C |
| Package / Case： | PDIP-16 |
| Packaging： | Tube |
| Mounting Style： | Through Hole |
| Number of Input Lines： | 1 Line |
| Factory Pack Quantity： | 25 |
| Part # Aliases： | 74HC259N |
74HC259N,652相关文档
- Application note: Pin FMEA 74HC/74HCT family (v.1.0)
- PCN: Transfer remaining DIP packages from APB to Vigilant at Bangkok Thailand (phase 5)
- Application note: AN11044
- Block diagram: mna573
- PCN: Final Product Change Notification
- PCN: Customer Information Notification
