SN54/74LS151
8-INPUT MULTIPLEXER
The TTL/MSI SN54/74LS151 is a high speed 8-input Digital Multiplexer.
It provides, in one package, the ability to select one bit of data from up to eight
sources. The LS151 can be used as a universal function generator to
generate any logic function of four variables. Both assertion and negation
outputs are provided.
8-INPUT MULTIPLEXER
LOW POWER SCHOTTKY
Schottky Process for High Speed
Multifunction Capability
On-Chip Select Logic Decoding
Fully Buffered Complementary Outputs
Input Clamp Diodes Limit High Speed Termination Effects
J SUFFIX
CERAMIC
CASE 620-09
16
CONNECTION DIAGRAM DIP (TOP VIEW)
1
N SUFFIX
PLASTIC
CASE 648-08
16
1
D SUFFIX
SOIC
CASE 751B-03
16
1
ORDERING INFORMATION
SN54LSXXXJ Ceramic
SN74LSXXXN Plastic
SN74LSXXXD SOIC
PIN NAMES
LOADING (Note a)
HIGH
LOW
S S
0
Select Inputs
Enable (Active LOW) Input
Multiplexer Inputs
Multiplexer Output (Note b)
Complementary Multiplexer Output
(Note b)
0.5 U.L.
0.5 U.L.
0.5 U.L.
10 U.L.
10 U.L.
0.25 U.L.
0.25 U.L.
0.25 U.L.
5 (2.5) U.L.
5 (2.5) U.L.
2
E
LOGIC SYMBOL
I I
0
7
Z
Z
NOTES:
a) 1 TTL Unit Load (U.L.) = 40 µA HIGH/1.6 mA LOW.
b) The Output LOW drive factor is 2.5 U.L. for Military (54) and 5 U.L. for Commercial (74)
Temperature Ranges.
FAST AND LS TTL DATA
5-252
