型号: 74LVC4245APW,112
厂商: NXP Semiconductors NXP Semiconductors
标准:
分类: 半导体集成电路 - IC
描述: bus transceivers xcvr 8bit lvl shiftr
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载2 >> 第三方平台下载 >>

74LVC4245APW,112的详细信息

Manufacturer: NXP
Product Category: Bus Transceivers
RoHS: Yes
Brand: NXP Semiconductors
Logic Type: CMOS
Logic Family: 74LVC
Number of Channels per Chip: 8
Input Level: LVTTL
Output Level: LVTTL
Output Type: 3-State
High Level Output Current: - 24 mA
Low Level Output Current: 24 mA
Propagation Delay Time: 10 ns
Supply Voltage - Max: 3.6 V, 5.5 V
Supply Voltage - Min: 1.5 V
Maximum Operating Temperature: + 125 C
Package / Case: TSSOP-24
Packaging: Tube
Function: Bus Transceiver with Voltage Translation
Maximum Power Dissipation: 500 mW
Minimum Operating Temperature: - 40 C
Mounting Style: SMD/SMT
Number of Circuits: 1
Polarity: Non-Inverting
Factory Pack Quantity: 63
Part # Aliases: 74LVC4245APW
74LVC4245A
Octal dual supply translating transceiver; 3-state
Rev. 10 — 18 December 2012
Product data sheet
1. General description
The 74LVC4245A is an octal dual supply translating transceiver featuring non-inverting
3-state bus compatible outputs in both send and receive directions. It is designed to
interface between a 3 V and 5 V bus in a mixed 3 V and 5 V supply environment.
The device features an output enable input (pin OE) for easy cascading and a
send/receive input (pin DIR) for direction control. Pin OE controls the outputs so that the
buses are effectively isolated.
In suspend mode, when VCC(A) is zero, there will be no current flow from one supply to the
other supply. The A-outputs must be set 3-state and the voltage on the A-bus must be
smaller than Vdiode (typical 0.7 V).
VCC(A) VCC(B), except in suspend mode.
2. Features and benefits
5 V tolerant inputs/outputs, for interfacing with 5 V logic
Wide supply voltage range:
3 V bus (VCC(B)): 1.5 V to 3.6 V
5 V bus (VCC(A)): 1.5 V to 5.5 V
CMOS low-power consumption
Direct interface with TTL levels
Inputs accept voltages up to 5.5 V
High-impedance when VCC(A) = 0 V
Complies with JEDEC standard no. JESD8B/JESD36
ESD protection:
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V
Multiple package options
Specified from 40 C to +85 C and 40 C to +125 C
