CMOS 180 MHz
a
DDS/DAC Synthesizer
AD9851
FUNCTIONAL BLOCK DIAGRAM
FEATURES
180 MHz Clock Rate with Selectable 6
؋
 Reference Clock
Multiplier
GND
+V
S
On-Chip High Performance 10-Bit DAC and High Speed
Comparator with Hysteresis
SFDR >43 dB @ 70 MHz AOUT
32-Bit Frequency Tuning Word
Simplified Control Interface: Parallel or Serial
Asynchronous Loading Format
5-Bit Phase Modulation and Offset Capability
Comparator Jitter <80 ps p-p @ 20 MHz
+2.7 V to +5.25 V Single Supply Operation
Low Power: 555 mW @ 180 MHz
Power-Down Function, 4 mW @ +2.7 V
Ultrasmall 28-Lead SSOP Packaging
AD9851
DAC R
SET
REF
6
؋
 REFCLK
CLOCK IN
MULTIPLIER
10-BIT
DAC
ANALOG
OUT
HIGH SPEED
DDS
MASTER
RESET
PHASE
AND
CONTROL
WORDS
32-BIT
TUNING
WORD
ANALOG
IN
FREQUENCY
UPDATE/DATA
REGISTER
FREQUENCY/PHASE
DATA REGISTER
CLOCK OUT
RESET
WORD LOAD
CLOCK
CLOCK OUT
DATA INPUT REGISTER
SERIAL
LOAD
COMPARATOR
PARALLEL
LOAD
1 BIT
؋

40 LOADS
8 BITS
؋

5 LOADS
APPLICATIONS
FREQUENCY, PHASE
AND CONTROL DATA INPUT
Frequency/Phase-Agile Sine Wave Synthesis
Clock Recovery and Locking Circuitry for Digital
Communications
Digitally Controlled ADC Encode Generator
Agile L.O. Applications in Communications
Quadrature Oscillator
CW, AM, FM, FSK, MSK Mode Transmitter
GENERAL DESCRIPTION
The AD9851 contains an internal high speed comparator that
can be configured to accept the (externally) filtered output of
the DAC to generate a low jitter output pulse.
The AD9851 is a highly integrated device that uses advanced
DDS technology, coupled with an internal high speed, high
performance D/A converter, and comparator, to form a digitally-
programmable frequency synthesizer and clock generator func-
tion. When referenced to an accurate clock source, the AD9851
generates a stable frequency and phase-programmable digitized
analog output sine wave. This sine wave can be used directly as
a frequency source, or internally converted to a square wave for
agile-clock generator applications. The AD9851’s innovative
high speed DDS core accepts a 32-bit frequency tuning word,
which results in an output tuning resolution of approximately
0.04 Hz with a 180 MHz system clock. The AD9851 contains a
unique 6× REFCLK Multiplier circuit that eliminates the need
for a high speed reference oscillator. The 6× REFCLK Multiplier
has minimal impact on SFDR and phase noise characteristics.
The AD9851 provides five bits of programmable phase modula-
tion resolution to enable phase shifting of its output in incre-
ments of 11.25°.
The frequency tuning, control and phase modulation words are
asynchronously loaded into the AD9851 via parallel or serial
loading format. The parallel load format consists of five itera-
tive loads of an 8-bit control word (byte). The first 8-bit byte
controls output phase, 6× REFCLK Multiplier, power-down
enable and loading format; the remaining bytes comprise the
32-bit frequency tuning word. Serial loading is accomplished
via a 40-bit serial data stream entering through one of the parallel
input bus lines. The AD9851 uses advanced CMOS technology
to provide this breakthrough level of functionality on just 555 mW
of power dissipation (+5 V supply), at the maximum clock rate of
180 MHz.
The AD9851 is available in a space-saving 28-lead SSOP, sur-
face mount package that is pin-for-pin compatible with the
popular AD9850 125 MHz DDS. It is specified to operate over
the extended industrial temperature range of –40°C to +85°C at
>3.0 V supply voltage. Below 3.0 V, the specifications apply
over the commercial temperature range of 0°C to +85°C.
REV. C
Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties
which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Analog Devices.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781/329-4700
Fax: 781/326-8703
World Wide Web Site: http://www.analog.com
© Analog Devices, Inc., 1999
