Image ADC0804
型号: ADC0804
厂商: Texas Instruments Texas Instruments
分类: 集成电路
描述: 8-bit uP compatible A/D converters
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >>

ADC0804的详细信息

  • 亲,您要的详细信息都在下载文档里了!

    本地下载

November 1999
ADC0801/ADC0802/ADC0803/ADC0804/ADC0805
8-Bit µP Compatible A/D Converters
n Differential analog voltage inputs
n Logic inputs and outputs meet both MOS and TTL
voltage level specifications
n Works with 2.5V (LM336) voltage reference
n On-chip clock generator
n 0V to 5V analog input voltage range with single 5V
supply
General Description
The ADC0801, ADC0802, ADC0803, ADC0804 and
ADC0805 are CMOS 8-bit successive approximation A/D
converters that use
a
differential potentiometric
ladder — similar to the 256R products. These converters are
designed to allow operation with the NSC800 and INS8080A
derivative control bus with TRI-STATE® output latches di-
rectly driving the data bus. These A/Ds appear like memory
locations or I/O ports to the microprocessor and no interfac-
ing logic is needed.
n No zero adjust required
n 0.3" standard width 20-pin DIP package
n 20-pin molded chip carrier or small outline package
n Operates ratiometrically or with 5 VDC, 2.5 VDC, or
analog span adjusted voltage reference
Differential analog voltage inputs allow increasing the
common-mode rejection and offsetting the analog zero input
voltage value. In addition, the voltage reference input can be
adjusted to allow encoding any smaller analog voltage span
to the full 8 bits of resolution.
Key Specifications
n Resolution
8 bits
LSB and 1 LSB
1
1
2
±
±
±
n Total error
n Conversion time
4
LSB,
Features
100 µs
n Compatible with 8080 µP derivatives — no interfacing
logic needed - access time - 135 ns
n Easy interface to all microprocessors, or operates “stand
alone”
Connection Diagram
ADC080X
Dual-In-Line and Small Outline (SO) Packages
DS005671-30
See Ordering Information
Ordering Information
TEMP RANGE
0˚C TO 70˚C
ADC0802LCWM
ADC0804LCWM
0˚C TO 70˚C
−40˚C TO +85˚C
ADC0801LCN
ADC0802LCN
ADC0803LCN
1
±
±
±
±
4
2
2
Bit Adjusted
Bit Unadjusted
Bit Adjusted
1
1
ERROR
1Bit Unadjusted
ADC0804LCN
ADC0805LCN/ADC0804LCJ
PACKAGE OUTLINE
M20B — Small
Outline
N20A — Molded DIP
TRI-STATE® is a registered trademark of National Semiconductor Corp.
Z-80® is a registered trademark of Zilog Corp.
© 1999 National Semiconductor Corporation
DS005671
www.national.com
