ADC0804LCN的详细信息

Manufacturer: Texas Instruments
Product Category: Analog to Digital Converters - ADC
RoHS: No
Number of Channels: 1 Channel
Architecture: SAR
Conversion Rate: 10 kS/s
Resolution: 8 bit
Input Type: Differential
Interface Type: Parallel
Operating Supply Voltage: 5 V
Maximum Operating Temperature: + 70 C
Mounting Style: Through Hole
Package / Case: PDIP-20
Brand: Texas Instruments
Maximum Power Dissipation: 875 mW
Minimum Operating Temperature: 0 C
Number of Converters: 1
Packaging: Tube
Product: ADC
Series: ADC0804-N
Factory Pack Quantity: 18
Voltage Reference: 2.5 V
SNOSBI1B NOVEMBER 2009REVISED FEBRUARY 2013
1
FEATURES
DESCRIPTION
The ADC0801, ADC0802, ADC0803, ADC0804 and
Compatible with 8080 µP derivatives – no
ADC0805 are CMOS 8-bit successive approximation
A/D converters that use a differential potentiometric
ladder — similar to the 256R products. These
converters are designed to allow operation with the
NSC800 and INS8080A derivative control bus with
TRI-STATE output latches directly driving the data
bus. These A/Ds appear like memory locations or I/O
ports to the microprocessor and no interfacing logic is
needed.
interfacing logic needed – access time 135 ns
Easy interface to all microprocessors, or
operates “stand alone”
Differential analog voltage inputs
Logic inputs and outputs meet both MOS and
TTL voltage level specifications
Works with 2.5V (LM336) voltage reference
On-chip clock generator
Differential analog voltage inputs allow increasing the
common-mode rejection and offsetting the analog
zero input voltage value. In addition, the voltage
reference input can be adjusted to allow encoding
any smaller analog voltage span to the full 8 bits of
resolution.
0V to 5V analog input voltage range with
single 5V supply
No zero adjust required
0.3" standard width 20-pin DIP package
20-pin molded chip carrier or small outline
package
CONNECTION DIAGRAM
Operates ratiometrically or with 5 VDC, 2.5 VDC
or analog span adjusted voltage reference
,
ADC080X
Dual-In-Line and Small Outline (SO) Packages
See Ordering Information
KEY SPECIFICATIONS
Resolution: 8 Bits
Total error: ±1/4 LSB, ±1/2 LSB and ±1 LSB
Conversion Time: 100 µs
Table 1. ORDERING INFORMATION
TEMP RANGE
±1/4 Bit Adjusted
0°C TO 70°C
0°C to 70°C
40°C TO +85°C
ADC0801LCN
ERROR
±1/2 Bit Unadjusted
±1/2 Bit Adjusted
±1Bit Unadjusted
ADC0802LCWM
ADC0802LCN
ADC0803LCN
ADC0804LCWM
ADC0804LCN
ADC0805LCN/ADC0804LCJ
PACKAGE OUTLINE
Z-80® is a registered trademark of Zilog Corp.
M20B — Small Outline
N20A — Molded DIP
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Copyright © 2009–2013, Texas Instruments Incorporated
