Image AT89C51-24PI
型号: AT89C51-24PI
厂商: Atmel Atmel
分类: 集成电路嵌入式 - 微控制器
描述: IC mcu 8bit 4kb flash 40dip
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >>

AT89C51-24PI的详细信息

Datasheets:
AT89C51:
Product Photos:
40-DIP Pkg:
40-DIP:
Standard Package : 9
Category: Integrated Circuits (ICs)
Family: Embedded - Microcontrollers
Series: 89C
Packaging : Tube
Core Processor: 80C51
Core Size: 8-Bit
Speed: 24MHz
Connectivity: UART/USART
Peripherals: -
Number of I/O: 32
Program Memory Size: 4KB (4K x 8)
Program Memory Type: FLASH
EEPROM Size: -
RAM Size: 128 x 8
Voltage - Supply (Vcc/Vdd): 4 V ~ 6 V
Data Converters: -
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C
Package / Case: 40-DIP (0.600", 15.24mm)
Supplier Device Package: 40-PDIP
Features
Compatible with MCS-51Products
4K Bytes of In-System Reprogrammable Flash Memory
– Endurance: 1,000 Write/Erase Cycles
Fully Static Operation: 0 Hz to 24 MHz
Three-level Program Memory Lock
128 x 8-bit Internal RAM
32 Programmable I/O Lines
Two 16-bit Timer/Counters
Six Interrupt Sources
Programmable Serial Channel
Low-power Idle and Power-down Modes
8-bit
Microcontroller
with 4K Bytes
Flash
Description
The AT89C51 is a low-power, high-performance CMOS 8-bit microcomputer with 4K
bytes of Flash programmable and erasable read only memory (PEROM). The device
is manufactured using Atmel’s high-density nonvolatile memory technology and is
compatible with the industry-standard MCS-51 instruction set and pinout. The on-chip
Flash allows the program memory to be reprogrammed in-system or by a conven-
tional nonvolatile memory programmer. By combining a versatile 8-bit CPU with Flash
on a monolithic chip, the Atmel AT89C51 is a powerful microcomputer which provides
a highly-flexible and cost-effective solution to many embedded control applications.
AT89C51
Not Recommended
for New Designs.
Use AT89S51.
PDIP
Pin Configurations
P1.0
P1.1
P1.2
P1.3
P1.4
P1.5
P1.6
P1.7
RST
1
2
3
4
5
6
7
8
9
40 VCC
39 P0.0 (AD0)
38 P0.1 (AD1)
37 P0.2 (AD2)
36 P0.3 (AD3)
35 P0.4 (AD4)
34 P0.5 (AD5)
33 P0.6 (AD6)
32 P0.7 (AD7)
31 EA/VPP
(RXD) P3.0 10
(TXD) P3.1 11
(INT0) P3.2 12
(INT1) P3.3 13
(T0) P3.4 14
(T1) P3.5 15
(WR) P3.6 16
(RD) P3.7 17
XTAL2 18
PQFP/TQFP
30 ALE/PROG
29 PSEN
28 P2.7 (A15)
27 P2.6 (A14)
26 P2.5 (A13)
25 P2.4 (A12)
24 P2.3 (A11)
23 P2.2 (A10)
22 P2.1 (A9)
21 P2.0 (A8)
XTAL1 19
P1.5
P1.6
1
2
3
4
5
6
7
8
9
33 PO.4 (AD4)
32 P0.5 (AD5)
31 P0.6 (AD6)
30 P0.7 (AD7)
29 EA/VPP
GND 20
P1.7
PLCC
RST
(RXD) P3.0
NC
28 NC
(TXD) P3.1
(INT0) P3.2
(INT1) P3.3
27 ALE/PROG
26 PSEN
25 P2.7 (A15)
24 P2.6 (A14)
23 P2.5 (A13)
(T0) P3.4 10
(T1) P3.5 11
P1.5
P1.6
P1.7
7
8
9
39 PO.4 (AD4)
38 P0.5 (AD5)
37 P0.6 (AD6)
36 P0.7 (AD7)
35 EA/VPP
RST 10
(RXD) P3.0 11
NC 12
34 NC
(TXD) P3.1 13
(INT0) P3.2 14
(INT1) P3.3 15
(T0) P3.4 16
(T1) P3.5 17
33 ALE/PROG
32 PSEN
31 P2.7 (A15)
30 P2.6 (A14)
29 P2.5 (A13)
Rev. 0265G–02/00
