型号: AT89C52-24PC
厂商: Atmel Atmel
分类: 集成电路嵌入式 - 微控制器
描述: IC mcu 8bit 8kb flash 40dip
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >>

AT89C52-24PC的详细信息

Datasheets:
AT89C52:
Product Photos:
40-DIP Pkg:
40-DIP:
Standard Package : 9
Category: Integrated Circuits (ICs)
Family: Embedded - Microcontrollers
Series: 89C
Packaging : Tube
Core Processor: 8051
Core Size: 8-Bit
Speed: 24MHz
Connectivity: SIO, UART/USART
Peripherals: -
Number of I/O: 32
Program Memory Size: 8KB (8K x 8)
Program Memory Type: FLASH
EEPROM Size: -
RAM Size: 256 x 8
Voltage - Supply (Vcc/Vdd): 4 V ~ 6 V
Data Converters: -
Oscillator Type: Internal
Operating Temperature: 0°C ~ 70°C
Package / Case: 40-DIP (0.600", 15.24mm)
Supplier Device Package: 40-PDIP
Features
Compatible with MCS-51Products
8K Bytes of In-System Reprogrammable Flash Memory
Endurance: 1,000 Write/Erase Cycles
Fully Static Operation: 0 Hz to 24 MHz
Three-level Program Memory Lock
256 x 8-bit Internal RAM
32 Programmable I/O Lines
Three 16-bit Timer/Counters
Eight Interrupt Sources
Programmable Serial Channel
Low-power Idle and Power-down Modes
8-bit
Microcontroller
with 8K Bytes
Flash
Description
The AT89C52 is a low-power, high-performance CMOS 8-bit microcomputer with 8K
bytes of Flash programmable and erasable read only memory (PEROM). The device
is manufactured using Atmel’s high-density nonvolatile memory technology and is
compatible with the industry-standard 80C51 and 80C52 instruction set and pinout.
The on-chip Flash allows the program memory to be reprogrammed in-system or by a
conventional nonvolatile memory programmer. By combining a versatile 8-bit CPU
with Flash on a monolithic chip, the Atmel AT89C52 is a powerful microcomputer
which provides a highly-flexible and cost-effective solution to many embedded control
applications.
AT89C52
Not Recommended
for New Designs.
Use AT89S52.
PDIP
Pin Configurations
(T2) P1.0
(T2 EX) P1.1
P1.2
1
2
3
4
5
6
7
8
9
40 VCC
PQFP/TQFP
39 P0.0 (AD0)
38 P0.1 (AD1)
37 P0.2 (AD2)
36 P0.3 (AD3)
35 P0.4 (AD4)
34 P0.5 (AD5)
33 P0.6 (AD6)
32 P0.7 (AD7)
31 EA/VPP
P1.3
P1.4
P1.5
P1.6
P1.7
RST
P1.5
P1.6
1
2
3
4
5
6
7
8
9
33 P0.4 (AD4)
32 P0.5 (AD5)
31 P0.6 (AD6)
30 P0.7 (AD7)
29 EA/VPP
(RXD) P3.0 10
(TXD) P3.1 11
(INT0) P3.2 12
(INT1) P3.3 13
(T0) P3.4 14
(T1) P3.5 15
(WR) P3.6 16
(RD) P3.7 17
XTAL2 18
30 ALE/PROG
29 PSEN
P1.7
RST
28 P2.7 (A15)
27 P2.6 (A14)
26 P2.5 (A13)
25 P2.4 (A12)
24 P2.3 (A11)
23 P2.2 (A10)
22 P2.1 (A9)
21 P2.0 (A8)
(RXD) P3.0
NC
28 NC
(TXD) P3.1
(INT0) P3.2
(INT1) P3.3
27 ALE/PROG
26 PSEN
25 P2.7 (A15)
24 P2.6 (A14)
23 P2.5 (A13)
(T0) P3.4 10
iT1) P3.5 11
XTAL1 19
GND 20
PLCC
P1.5
P1.6
P1.7
7
8
9
39 P0.4 (AD4)
38 P0.5 (AD5)
37 P0.6 (AD6)
36 P0.7 (AD7)
35 EA/VPP
34 NC
RST 10
(RXD) P3.0 11
NC 12
(TXD) P3.1 13
(INT0) P3.2 14
(INT1) P3.3 15
(T0) P3.4 16
(T1) P3.5 17
33 ALE/PROG
32 PSEN
31 P2.7 (A15)
30 P2.6 (A14)
29 P2.5 (A13)
Rev. 0313H–02/00
