Image AT89S52-24PU
型号: AT89S52-24PU
厂商: Atmel Atmel
标准:
分类: 半导体集成电路 - IC
描述: 8-bit microcontrollers - mcu 8kb flash 256b ram 33mhz 4.0V-5.5V
PDF: 预览
报错 收藏

AT89S52-24PU的详细信息

Manufacturer: Atmel
Product Category: 8-bit Microcontrollers - MCU
RoHS: Yes
Brand: Atmel
Core: 8051
Data Bus Width: 8 bit
Maximum Clock Frequency: 33 MHz
Program Memory Size: 8 kB
Data RAM Size: 256 B
On-Chip ADC: No
Operating Supply Voltage: 4 V to 5.5 V
Maximum Operating Temperature: + 85 C
Package / Case: PDIP
Mounting Style: Through Hole
Interface Type: UART
Minimum Operating Temperature: - 40 C
Number of Programmable I/Os: 32
Number of Timers: 3
Processor Series: AT89x
Program Memory Type: Flash
Series: 89S
Factory Pack Quantity: 10
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 4 V
Features
Compatible with MCS®-51 Products
8K Bytes of In-System Programmable (ISP) Flash Memory
– Endurance: 10,000 Write/Erase Cycles
4.0V to 5.5V Operating Range
Fully Static Operation: 0 Hz to 33 MHz
Three-level Program Memory Lock
256 x 8-bit Internal RAM
32 Programmable I/O Lines
8-bit
Three 16-bit Timer/Counters
Eight Interrupt Sources
Microcontroller
with 8K Bytes
In-System
Programmable
Flash
Full Duplex UART Serial Channel
Low-power Idle and Power-down Modes
Interrupt Recovery from Power-down Mode
Watchdog Timer
Dual Data Pointer
Power-off Flag
Fast Programming Time
Flexible ISP Programming (Byte and Page Mode)
Green (Pb/Halide-free) Packaging Option
AT89S52
1. Description
The AT89S52 is a low-power, high-performance CMOS 8-bit microcontroller with 8K
bytes of in-system programmable Flash memory. The device is manufactured using
Atmel’s high-density nonvolatile memory technology and is compatible with the indus-
try-standard 80C51 instruction set and pinout. The on-chip Flash allows the program
memory to be reprogrammed in-system or by a conventional nonvolatile memory pro-
grammer. By combining a versatile 8-bit CPU with in-system programmable Flash on
a monolithic chip, the Atmel AT89S52 is a powerful microcontroller which provides a
highly-flexible and cost-effective solution to many embedded control applications.
The AT89S52 provides the following standard features: 8K bytes of Flash, 256 bytes
of RAM, 32 I/O lines, Watchdog timer, two data pointers, three 16-bit timer/counters, a
six-vector two-level interrupt architecture, a full duplex serial port, on-chip oscillator,
and clock circuitry. In addition, the AT89S52 is designed with static logic for operation
down to zero frequency and supports two software selectable power saving modes.
The Idle Mode stops the CPU while allowing the RAM, timer/counters, serial port, and
interrupt system to continue functioning. The Power-down mode saves the RAM con-
tents but freezes the oscillator, disabling all other chip functions until the next interrupt
or hardware reset.
1919D–MICRO–6/08
