型号: BAV70
厂商: Fairchild Semiconductor Fairchild Semiconductor
标准:
分类: 半导体分离式半导体
描述: diodes - general purpose, power, switching 70v 200ma
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

BAV70的详细信息

Manufacturer: Fairchild Semiconductor
Product Category: Diodes - General Purpose, Power, Switching
RoHS: Yes
Peak Reverse Voltage: 70 V
Forward Continuous Current: 0.2 A
Max Surge Current: 2 A
Configuration: Dual Common Cathode
Recovery Time: 6 ns
Forward Voltage Drop: 1.25 V at 0.15 A
Maximum Reverse Leakage Current: 5 uA
Mounting Style: SMD/SMT
Package / Case: SOT-23
Packaging: Reel
Brand: Fairchild Semiconductor
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Series: BAV70
Factory Pack Quantity: 3000
Part # Aliases: BAV70_NL
Unit Weight: 25 mg
BAV70 / 74
Connection Diagram
3
3
3
A4
2
1
2
MARKING
BAV70 A4 BAV74 JA
1
1
2
SOT-23
Small Signal Diode
Absolute Maximum Ratings *
T
= 25°C unless otherwise noted
A
Symbol
Parameter
Value
Units
V
Maximum Repetitive Reverse Voltage
BAV70
BAV74
70
50
V
V
RRM
I
I
Average Rectified Forward Current
200
mA
F(AV)
Non-repetitive Peak Forward Surge Current
Pulse Width = 1.0 second
FSM
1.0
2.0
A
A
Pulse Width = 1.0 microsecond
T
T
Storage Temperature Range
-55 to +150
150
°C
°C
STG
J
Operating Junction Temperature
* These ratings are limiting values above which the serviceability of the diode may be impaired.
NOTES:
1) These ratings are based on a maximum junction temperature of 150 degrees C.
2) These are steady limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.
Thermal Characteristics
Symbol
Parameter
Value
350
Units
mW
P
Power Dissipation
Thermal Resistance, Junction to Ambient
D
R
357
°C/W
θJA
Electrical Characteristics T =25°C unless otherwise noted
A
Symbol
Parameter
Test Conditions
Min.
Max.
Units
V
V
Breakdown Voltage
BAV70
BAV74
I
I
= 100µA
= 5.0µA
75
50
V
V
R
F
R
R
Forward Voltage
Reverse Leakage
BAV70
I
I
I
I
I
= 1.0mA
= 10mA
= 50mA
= 150mA
= 100mA
715
855
1.0
1.25
1.0
mV
mV
V
V
V
F
F
F
F
F
BAV74
BAV70
I
V
V
V
V
V
= 25V, T = 150°C
= 70V
= 70V, T = 150°C
= 50V
60
5.0
100
100
100
µA
µA
µA
nA
µA
R
R
R
R
R
R
A
A
BAV74
= 50V, T = 150°C
A
C
Total Capacitance
BAV70
BAV74
V
V
= 0V, f = 1.0MHz
= 0V, f = 1.0MHz
1.5
2.0
pF
pF
T
R
R
t
Reverse Recovery Time
BAV70
I
= I = 10mA, I = 1.0mA,
6.0
ns
rr
F
R
RR
R
= 100Ω
L
BAV74
I
= I = 10mA, I = 1.0mA,
4.0
ns
F
R
RR
R
= 100Ω
L
©2004 Fairchild Semiconductor Corporation
BAV70 / 74, Rev. D1
