DreamCity Innovations
WCH CH340G Datasheet
WCH CH340 Series USB Interface Integrated Circuit
CH340G USB to UART Interface
Datasheet
WCH Version 1E
DreamCity Version 1.0
Disclaimer from DreamCity Innovations
This is a third-party translation of WCH’s CH340 Series chipset’s Chinese datasheet, with
information regarding CH340G chip extracted. The two other chips sharing the same
datasheet, CH340R and C340T, have official English version.
1. Overview
CH340 is a series of USB bus adapters, that provides serial, parallel or IrDA interfaces over
the USB bus (note: CH340G supports serial interface only). The CH340G integrate circuit
provides common MODEM signals to allow adding a UART to a computer, or converting
existing UART devices to USB interface.
2. Features
Full-speed USB interface, compatible with USB 2.0 interface.
Operates with a minimum amount of external components: a crystal and a minimum of four
capacitors.
Provides a virtual serial port for upgrading existing serial port devices or adding serial ports
to a PC.
Supports all existing applications using serial ports without the need of changing existing
code.
Hardware full-duplex serial interface with internal FIFO. Baud rate range from 50bps to
2Mbps.
Supports common flow control signals RTS, DTR, DCD, RI, DSR and CTS.
Supports RS232, RS422 and RS485 with external level shifting components.
Uses CH341 driver.
Supports 5V and 3.3V operation.
RoHS-compliant narrow body SO-16 package.
DreamCity Innovations
Page 1 of 6
WCH CH340G Datasheet
