CKSR 15-NP的详细信息
| Datasheets： | |
|---|---|
| CKSR Series： | |
| Product Photos： | |
| CKSR 15-NP： | |
| Product Training Modules： | |
| CAS Modules Overview： | |
| Catalog Drawings： | |
| CKSR Series Side： | |
| Standard Package ： | 50 |
| Category： | Sensors, Transducers |
| Family： | Current Transducers |
| Series： | CKSR |
| Packaging ： | Tube |
| For Measuring： | AC/DC |
| Sensor Type： | Flux Gate, Closed Loop |
| Current - Sensing： | 15A |
| Number of Channels： | 1 |
| Output： | Ratiometric, Voltage |
| Sensitivity： | 41.67mV/A |
| Frequency： | 300kHz |
| Linearity： | ±1% |
| Accuracy： | ±0.8% |
| Voltage - Supply： | 4.75 V ~ 5.25 V |
| Response Time： | 0.3µs |
| Current - Supply (Max)： | 20mA |
| Operating Temperature： | -40°C ~ 105°C |
| Polarization： | Bidirectional |
| Mounting Type： | Through Hole |
| Package / Case： | Module |
| Dynamic Catalog： | CKSR |
| Other Names： | 398-1096-5CKSR15NP |
