CSD16407Q5C的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | MOSFET |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Transistor Polarity： | N-Channel |
| Vds - Drain-Source Breakdown Voltage： | 25 V |
| Vgs - Gate-Source Breakdown Voltage： | 25 V |
| Id - Continuous Drain Current： | 100 A |
| Rds On - Drain-Source Resistance： | 2.5 mOhms |
| Configuration： | Single |
| Vgs th - Gate-Source Threshold Voltage： | 1.6 V |
| Qg - Gate Charge： | 13.3 nC |
| Pd - Power Dissipation： | 3.1 W |
| Mounting Style： | SMD/SMT |
| Package / Case： | VSON-8 Clip |
| Packaging： | Reel |
| Fall Time： | 9 ns |
| Forward Transconductance - Min： | 111 S |
| Rise Time： | 18.4 ns |
| Series： | CSD16407Q5C |
| Factory Pack Quantity： | 2500 |
| Tradename： | NexFET |
| Typical Turn-Off Delay Time： | 16 ns |
CSD16407Q5C相关文档
- PCN: TI - PCN - 7-30-10
- Evaluation Kits: Sync Buck, monitor for Battery charging & monitoring for PCs (12.6V @ 8A)
- Evaluation Kits: Sync Buck, Linear Regulator (1.5V @ 9A, 0.75V @ 3A)
- Evaluation Kits: DualCool? NexFET? Power MOSFETs and TPS40304 Buck Controller Evaluation Module
- PCN: Qualification of Reduced Wire Bond diameter for the Family of Discrete Clip & Power Block Devices
