型号: DS1302
厂商: Maxim Integrated Maxim Integrated
分类: 半导体集成电路 - IC
描述: real time clock trickle-charge timekeeping chip
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载2 >> 第三方平台下载 >>

DS1302的详细信息

Manufacturer: Maxim Integrated
Product Category: Real Time Clock
RoHS: No
Function: Clock, Calendar, Trickle Charger, NV Timekeeping RAM
RTC Bus Interface: Serial
Time Format: HH
RTC Memory Size: 31 B
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2 V
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
Mounting Style: Through Hole
Package / Case: PDIP N
Packaging: Tube
Battery Backup Switching: Yes
Brand: Maxim Integrated
Series: DS1302
Factory Pack Quantity: 50
Part # Aliases: 90-13020-000
DS1302
Trickle-Charge Timekeeping Chip
FEATURES
PIN CONFIGURATIONS
Real-Time Clock Counts Seconds, Minutes,
Hours, Date of the Month, Month, Day of the
Week, and Year with Leap-Year
TOP VIEW
VCC1
SCLK
I/O
VCC2
X1
1
2
3
4
8
7
6
5
Compensation Valid Up to 2100
31 x 8 Battery-Backed General-Purpose RAM
Serial I/O for Minimum Pin Count
2.0V to 5.5V Full Operation
X2
CE
GND
DIP (300 mils)
Uses Less than 300nA at 2.0V
Single-Byte or Multiple-Byte (Burst Mode)
Data Transfer for Read or Write of Clock or
RAM Data
VCC2
X1
1
2
3
4
8
7
6
5
VCC1
SCLK
I/O
8-Pin DIP or Optional 8-Pin SO for Surface
Mount
X2
GND
CE
Simple 3-Wire Interface
TTL-Compatible (VCC = 5V)
SO (208 mils/150 mils)
Optional Industrial Temperature Range:
-40°C to +85°C
DS1202 Compatible
Underwriters Laboratories (UL®)
Recognized
ORDERING INFORMATION
PART
TEMP RANGE
PIN-PACKAGE
8 PDIP (300 mils)
8 PDIP (300 mils)
8 SO (208 mils)
8 SO (208 mils)
8 SO (150 mils)
8 SO (150 mils)
TOP MARK*
DS1302+
0°C to +70°C
-40°C to +85°C
0°C to +70°C
-40°C to +85°C
0°C to +70°C
-40°C to +85°C
DS1302
DS1302
DS1302S
DS1302S
DS1302Z
DS1302ZN
DS1302N+
DS1302S+
DS1302SN+
DS1302Z+
DS1302ZN+
+Denotes a lead-free/RoHS-compliant package.
*An N anywhere on the top mark indicates an industrial temperature grade device. A + anywhere on the top mark indicates a lead-free device.
UL is a registered trademark of Underwriters Laboratories, Inc.
For pricing, delivery, and ordering information, please contact Maxim Direct
at 1-888-629-4642, or visit Maxim’s website at www.maximintegrated.com.
REV: 120208
