Image H1102NL
型号: H1102NL
厂商: Pulse
标准:
分类: 无源元器件脉冲变压器
描述: module xfrmr sgl ethr lan 16soic
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 第三方平台下载 >>

H1102NL的详细信息

Datasheets:
10_100BASE-T Single Port SMD Magnetics:
Product Photos:
H1102(NL):
PCN Design/Specification:
Thermoplastic Header Design 28/Jun/2013:
Standard Package : 40
Category: Transformers
Family: Pulse Transformers
Series: -
Transformer Type: Isolation and Data Interface (Encapsulated)
Inductance: -
Turns Ratio - Primary: Secondary
E.T.: -
Mounting Type: Surface Mount
Size / Dimension: 12.70mm L x 7.11mm W
Height - Seated (Max): 6.22mm
Other Names: 553-1323
10/100BASE-T SINGLE PORT
SURFACE MOUNT MAGNETICS
With Various Turns Ratios
RoHS-5 peak reflow temperature rating 235°C
RoHS-6 peak reflow temperature rating 245°C°°
Meets IEEE 802.3 specification
Compact footprint for use in the most space-restrictive applications
Electrical Specifications @ 25°C — Operating Temperature 0°C to 70°C
RoHS-6 5
Compliant
Part
RoHS-5 4
Compliant
Part
Differential to Common
Insertion Loss
100kHz–100MHz
(db MAX)
Return Loss
Crosstalk
Hipot
(VRMS
MIN)
Turns Ratio
Mode Rejection
(dB TYP)
(dB TYP)
(dB TYP)
Number
Number
TX
RX
30MHz
-20
60MHz
-14
80MHz
-11.5
-11.5
-11.5
-11.5
-12
30MHz
-42
50MHz 100MHz 30MHz 60MHz 100MHz
H1100NL3a
H1101NL3a
H1102NL3a
H1121NL3c
H1183NL3a
H1199NL3a
HX1188NL1, 3a
H1100
__
2:1
1:1
-1.1
-1.1
-1.1
-1.1
-1.0
-0.9
-1.0
-37
-37
-37
-37
-40
-35
-37
-33
-33
-33
-30
-40
-30
-32
-45
-45
-45
-45
-35
-45
-45
-40
-40
-40
-40
-35
-45
-40
-35
-35
-35
-35
-35
-37
-35
1500
1500
1500
1500
1500
1500
1500
1.25:1 1:1
1:1 1:1
1:1.414 1:1
-20
-14
-42
H1102
H1121
H1183
H1199
HX1188 1
-20
-14
-42
-18
-12
-42
1:1
1:1
1:1
1:1
1:1
1:1
-18
-14
-40
-18
-12
-11
-40
-20
-14
-12
-42
HX1198 NL1, 3a HX1198 1
1:1
1:1
1:1
1:1
-1.0
-1.1
-20
-16
-14
-10
-12
-10
-42
-42
-37
-37
-32
-32
-45
-35
-40
-30
-35
-30
1500
1500
H1302NL3a
H1302
1. Operating temperature -40oC to +85oC
2. For Tape & Reel packaging, add a “T” suffix at the end of the part number when ordering, e.g. H1102T.
3. MSL = Moisture Sensitivity Level a=1 b=2 c=3 d=4
4. RoHS-5: Product does not contain 5 out of the 6 banned substances specified in the RoHS directive (product contains lead in applications
considered solder).
5. RoHS-6: Product does not contain 5 out of the 6 banned substances specified in the RoHS directive. Some internal connections may contain
lead in high-temperature solder (solder alloys containing more than 85% lead).
Mechanical
H110X, H1121, H1183,* H1199, HX1188, HX1198, H1302
* For part number H1183, all dimensions are the same, except the height is .220” (5,59 mm).
.350
.115
8,89
2,92
.050
1,27
.500
.059
1,50
12,70
.405 .270
10,20 6,86
.280
7,11
.380
9,53
MAX
MAX*
Date Code Country of Origin
.030
0,76
.020 .002
±
0,51 0,05
.236
5,97
0° – 8°
Inches
mm
Dimensions:
.004/0,10
16 Surfaces
.004
.050
1,27
Weight . . . . . . .0.9 grams
Tube . . . . . . . . . . 45/tube
Tape & Reel . . . . 600/reel
Unless otherwise specified,
.030 .035
to
.010
0,25
all tolerances are ±
0,76 0,89
MIN
.350
8,89
0,10
USA 858 674 8100 Germany 49 7032 7806 0 Singapore 65 6287 8998 Shanghai 86 21 32181071 China 86 755 33966678 Taiwan 886 3 4643715
www.pulseeng.com
1
H325.O (9/08)
