HT1621
RAM Mapping 32´4 LCD Controller for I/O MCU
Technical Document
·
·
·
Features
·
·
·
·
·
·
·
·
·
·
·
Operating voltage: 2.4V~5.2V
32´4 LCD driver
·
·
Built-in 256kHz RC oscillator
Built-in 32´4 bit display RAM
3-wire serial interface
External 32.768kHz crystal or 256kHz frequency
source input
Internal LCD driving frequency source
Software configuration feature
Data mode and command mode instructions
R/W address auto increment
Three data accessing modes
VLCD pin for adjusting LCD operating voltage
·
Selection of 1/2 or 1/3 bias, and selection of 1/2 or
1/3 or 1/4 duty LCD applications
·
·
·
·
·
·
Internal time base frequency sources
Two selectable buzzer frequencies (2kHz/4kHz)
Power down command reduces power consumption
Built-in time base generator and WDT
HT1621B: 48-pin SSOP/LQFP packages
HT1621D: 28-pin SKDIP package
HT1621G: Gold bumped chip
Time base or WDT overflow output
8 kinds of time base/WDT clock sources
General Description
systems. Only three or four lines are required for the in-
terface between the host controller and the HT1621.
The HT1621 contains a power down command to re-
duce power consumption.
The HT1621 is a 128 pattern (32´4), memory mapping,
and multi-function LCD driver. The S/W configuration
feature of the HT1621 makes it suitable for multiple LCD
applications including LCD modules and display sub-
Selection Table
HT162X
HT1620
HT1621
HT1622
HT16220
HT1623
HT1625
HT1626
COM
SEG
4
32
¾
Ö
4
32
Ö
8
32
Ö
8
32
¾
Ö
8
48
Ö
8
64
Ö
16
48
Ö
Built-in Osc.
Crystal Osc.
Ö
¾
Ö
Ö
Ö
Rev. 1.70
1
June 29, 2005
