HT7530/33/36/44/50 EOL Notification
EOL Notification
Holtek hereby formally gives End Of Life (EOL) notification that the HT7530, HT7533, HT7536, HT7544 and HT7550
(hereinafter denoted as HT75XX) 100mA Voltage Regulator will be phased out of production with a latest purchase
date of July 31st 2003. The suggested replacement device will be known as the HT7530-1, HT7533-1, HT7536-1,
HT7544-1 and HT7550-1 (hereinafter denoted as HT75XX-1) and will offer superior performance by providing lower
output voltage tolerance of 3% in addition to having an additional SOT25 packaging type.
The following shows the phase out schedule for the HT75XX and the cross references between the phased out devices
and the new release devices:
Last time buy date: July 31st 2003
·
-
Order placement deadline
Production stops: October 31st 2003
·
-
Cease production
-
Last delivery
-
Product reaches end of life status
·
Suggested replacement device: HT75XX-1
-
Output voltage tolerance of ±3%
-
Additional SOT25 package release
-
All devices are now available
-
Refer to the following tables for cross reference information.
Features Cross Reference
Part No.
HT75XX-1
HT75XX
Item
Output Voltage
Electrical Specification
Same
Same
Same
Same
HT7530-1
HT7533-1
HT7536-1
HT7544-1
HT7550-1
HT7530
HT7533
HT7536
HT7544
HT7550
Part No.
Tolerance
±3%
±5%
TO92 (Bulk, T&R)
TO92 (Bulk, T&R)
SOT89 (Bulk, T&R)
None
Package Form
SOT89 (T&R only)
SOT25 (T&R only)
75XX-1 (for TO92 and SOT89)
5XX1 (for SOT25)
HT75XX (for TO92 and SOT89)
None
Marking
Last order: Jul/31/2003
Availability
Now available
Last shipment: Oct/31/2003
1
November 29, 2002
