19-0960; Rev 2; 1/00
Chopper-Stabilized Op Amps
General Description
Features
Maxim’s ICL7650/ICL7653 are chopper-stabilized
amplifiers, ideal for low-level signal processing applica-
tions. Featuring high performance and versatility, these
devices combine low input offset voltage, low input bias
current, wide bandwidth, and exceptionally low drift
over time and temperature. Low offset is achieved
through a nulling scheme that provides continuous
error correction. A nulling amplifier alternately nulls
itself and the main amplifier. The result is an input offset
voltage that is held to a minimum over the entire operat-
ing temperature range.
ICL7650/53 are Improved Second Sources to
ICL7650B/53B
Lower Supply Current: 2mA
Low Offset Voltage: 1µV
No Offset Voltage Trimming Needed
High-Gain CMRR and PSRR: 120dB min
Lower Offset Drift with Time and Temperature
Extended Common-Mode Voltage Range
Low DC Input Bias Current: 10pA
Monolithic, Low-Power CMOS Design
The ICL7650B/ICL7653B are exact replacements for
Intersil’s ICL7650B/ICL7653B. These devices have a
10µV max offset voltage, a 0.1µV/°C max input offset
voltage temperature coefficient, and a 20pA max bias
current—all specified over the commercial temperature
range.
Ordering Information
A 14-pin version is available that can be used with
either an internal or external clock. The 14-pin version
has an output voltage clamp circuit to minimize over-
load recovery time.
PART
TEMP. RANGE
0°C to +70°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
-20°C to +85°C
-20°C to +85°C
-55°C to +125°C
-55°C to +125°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
-20°C to +85°C
-55°C to +125°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
PIN-PACKAGE
8 SO
ICL7650CSA
ICL7650CSD
ICL7650CPA
ICL7650CPD
ICL7650CTV
ICL7650C/D
ICL7650IJA
14 SO
8 Plastic DIP
14 Plastic DIP
8 TO-99
Applications
Condition Amplifier
Precision Amplifier
Instrumentation Amplifier
Thermocouples
Dice
8 CERDIP
14 CERDIP
8 CERDIP
14 CERDIP
8 SO
ICL7650IJD
ICL7650MTV
ICL7650MJD
ICL7650BCSA
ICL7650BCSD
ICL7650BCPA
ICL7650BCPD
ICL7650BCTV
ICL7650BC/D
ICL7653CSA
ICL7653CPA
ICL7653CTV
ICL7653IJA
Thermistors
Strain Gauges
14 SO
8 Plastic DIP
14 Plastic DIP
8 TO-99
Typical Operating Circuit
Dice
8 SO
8 Plastic DIP
8 TO-99
CLAMP
INPUT
8 CERDIP
8 CERDIP
8 SO
OUTPUT
ICL7653MTV
ICL7653BCSA
ICL7653BCPA
ICL7653BCTV
ICL7650
ICL7653
C
8 Plastic DIP
8 TO-99
R
C
INVERTING AMPLIFIER
WITH OPTIONAL CLAMP
Pin Configurations appear at end of data sheet.
