型号: IRF640
厂商: Vishay Siliconix Vishay Siliconix
分类: 半导体分离式半导体
描述: mosfet N-chan 200v 18 amp
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 第三方平台下载 >>

IRF640的详细信息

Manufacturer: Vishay
Product Category: MOSFET
RoHS: No
Brand: Vishay / Siliconix
Transistor Polarity: N-Channel
Vds - Drain-Source Breakdown Voltage: 200 V
Vgs - Gate-Source Breakdown Voltage: 20 V
Id - Continuous Drain Current: 18 A
Rds On - Drain-Source Resistance: 180 mOhms
Configuration: Single
Maximum Operating Temperature: + 150 C
Pd - Power Dissipation: 125 W
Mounting Style: Through Hole
Package / Case: TO-220-3
Packaging: Tube
Channel Mode: Enhancement
Fall Time: 36 ns
Minimum Operating Temperature: - 55 C
Rise Time: 51 ns
Factory Pack Quantity: 50
Typical Turn-Off Delay Time: 45 ns
IRF640, SiHF640
Vishay Siliconix
Power MOSFET
FEATURES
• Dynamic dV/dt Rating
PRODUCT SUMMARY
VDS (V)
200
Available
• Repetitive Avalanche Rated
• Fast Switching
R
DS(on) (Ω)
VGS = 10 V
0.18
RoHS*
Qg (Max.) (nC)
70
13
COMPLIANT
• Ease of Paralleling
Q
Q
gs (nC)
gd (nC)
• Simple Drive Requirements
39
Configuration
Single
• Compliant to RoHS Directive 2002/95/EC
D
DESCRIPTION
TO-220AB
Third generation Power MOSFETs from Vishay provide the
designer with the best combination of fast switching,
ruggedized device design, low on-resistance and
cost-effectiveness.
G
The TO-220AB package is universally preferred for all
commercial-industrial applications at power dissipation
levels to approximately 50 W. The low thermal resistance
and low package cost of the TO-220AB contribute to its
wide acceptance throughout the industry.
S
D
G
S
N-Channel MOSFET
ORDERING INFORMATION
TO-220AB
IRF640PbF
SiHF640-E3
IRF640
Package
Lead (Pb)-free
SnPb
SiHF640
ABSOLUTE MAXIMUM RATINGS (TC = 25 °C, unless otherwise noted)
PARAMETER
SYMBOL
LIMIT
UNIT
Drain-Source Voltage
Gate-Source Voltage
VDS
200
V
VGS
± 20
TC = 25 °C
TC = 100 °C
18
Continuous Drain Current
V
GS at 10 V
ID
11
A
Pulsed Drain Currenta
IDM
72
Linear Derating Factor
1.0
W/°C
mJ
A
Single Pulse Avalanche Energyb
Repetitive Avalanche Currenta
Repetitive Avalanche Energya
EAS
IAR
580
18
EAR
13
125
mJ
W
Maximum Power Dissipation
TC = 25 °C
PD
Peak Diode Recovery dV/dtc
dV/dt
TJ, Tstg
5.0
V/ns
Operating Junction and Storage Temperature Range
Soldering Recommendations (Peak Temperature)
- 55 to + 150
300d
°C
for 10 s
10
lbf · in
N · m
Mounting Torque
6-32 or M3 screw
1.1
Notes
a. Repetitive rating; pulse width limited by maximum junction temperature (see fig. 11).
b. VDD = 50 V, starting TJ = 25 °C, L = 2.7 mH, Rg = 25 Ω, IAS = 18 A (see fig. 12).
c. ISD 18 A, dI/dt 150 A/μs, VDD VDS, TJ 150 °C.
d. 1.6 mm from case.
* Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 91036
S11-0509-Rev. B, 21-Mar-11
www.vishay.com
1
This datasheet is subject to change without notice.
THE PRODUCT DESCRIBED HEREIN AND THIS DATASHEET ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
