L293D的详细信息

Manufacturer: STMicroelectronics
Product Category: Motor / Motion / Ignition Controllers & Drivers
RoHS: Yes
Brand: STMicroelectronics
Product: Stepper Motor Controllers / Drivers
Type: H-Bridge
Operating Supply Voltage: 4.5 V to 36 V
Output Current: 600 mA
Operating Temperature: - 40 C to + 150 C
Supply Current: 2 mA
Mounting Style: Through Hole
Package / Case: PowerDIP-16
Packaging: Tube
Number of Outputs: 2
Series: L293D
Factory Pack Quantity: 25
L293D
L293DD
®
PUSH-PULL FOUR CHANNEL DRIVER WITH DIODES
600mA OUTPUT CURRENT CAPABILITY
PER CHANNEL
1.2A PEAK OUTPUT CURRENT (non repeti-
tive) PER CHANNEL
ENABLE FACILITY
OVERTEMPERATURE PROTECTION
LOGICAL "0" INPUT VOLTAGE UP TO 1.5 V
(HIGH NOISE IMMUNITY)
INTERNAL CLAMP DIODES
SO(12+4+4)
Powerdip (12+2+2)
ORDERING NUMBERS:
L293DD
DESCRIPTION
L293D
The Device is a monolithic integrated high volt-
age, high current four channel driver designed to
accept standard DTL or TTL logic levels and drive
inductive loads (such as relays solenoides, DC
and stepping motors) and switching power tran-
sistors.
To simplify use as two bridges each pair of chan-
nels is equipped with an enable input. A separate
supply input is provided for the logic, allowing op-
eration at a lower voltage and internal clamp di-
odes are included.
This device is suitable for use in switching appli-
cations at frequencies up to 5 kHz.
The L293D is assembled in a 16 lead plastic
packaage which has 4 center pins connected to-
gether and used for heatsinking
The L293DD is assembled in a 20 lead surface
mount which has 8 center pins connected to-
gether and used for heatsinking.
BLOCK DIAGRAM
July 2003
1/7
