型号: L7805CV
厂商: STMicroelectronics STMicroelectronics
标准:
分类: 半导体集成电路 - IC
描述: linear voltage regulators 5.0V 1.0A positive
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

L7805CV的详细信息

Manufacturer: STMicroelectronics
Product Category: Linear Voltage Regulators
RoHS: Yes
Brand: STMicroelectronics
Output Type: Fixed
Output Voltage: 5 V
Output Current: 1.5 A
Load Regulation: 100 mV
Input Voltage MAX: 35 V
Line Regulation: 100 mV
Maximum Operating Temperature: + 125 C
Mounting Style: Through Hole
Package / Case: TO-220
Input Voltage MIN: 7 V
Minimum Operating Temperature: 0 C
Number of Outputs: 1
Packaging: Tube
Polarity: Positive
PSRR / Ripple Rejection - Typ: 62 dB
Series: L7805
Factory Pack Quantity: 1000
L78
Positive voltage regulator ICs
Datasheet
-
production data
Description
The L78 series of three-terminal positive
regulators is available in TO-220, TO-220FP,
D²PAK and DPAK packages and several fixed
output voltages, making it useful in a wide range
of applications.
These regulators can provide local on-card
regulation, eliminating the distribution problems
associated with single point regulation. Each type
embeds internal current limiting, thermal shut-
down and safe area protection, making it
essentially indestructible. If adequate heat sinking
is provided, they can deliver over 1 A output
current. Although designed primarily as fixed
voltage regulators, these devices can be used
with external components to obtain adjustable
voltage and currents.
TO-220
TO-220FP
DPAK
D²PAK
Features
Output current up to 1.5 A
Output voltages of 5; 6; 8; 8.5; 9; 12; 15; 18;
24 V
Thermal overload protection
Short circuit protection
Output transition SOA protection
2 % output voltage tolerance (A version)
Guaranteed in extended temperature range
(A version)
March 2014
DocID2143 Rev 32
1/58
This is information on a product in full production.
