型号: LM1117MPX-3.3/NOPB
厂商: Texas Instruments Texas Instruments
标准:
分类: 半导体集成电路 - IC
描述: ldo voltage regulators 800ma ldo linear reg
PDF: 预览
报错 收藏

LM1117MPX-3.3/NOPB的详细信息

Manufacturer: Texas Instruments
Product Category: LDO Voltage Regulators
RoHS: Yes
Input Voltage MAX: 15 V
Output Voltage: 1.8 V, 2.5 V, 2.85 V, 3.3 V, 5 V
Dropout Voltage - Max: 1.2 V
Output Current: 800 mA
Maximum Operating Temperature: + 125 C
Mounting Style: SMD/SMT
Package / Case: SOT-223-4
Brand: Texas Instruments
Minimum Operating Temperature: 0 C
Packaging: Reel
Series: LM1117-N
Factory Pack Quantity: 2000
SNOS412M FEBRUARY 2000REVISED MARCH 2013
LM1117-N/LM1117I 800mA Low-Dropout Linear Regulator
Check for Samples: LM1117-N, LM1117I
1
FEATURES
DESCRIPTION
The LM1117-N is a series of low dropout voltage
2
Available in 1.8V, 2.5V, 2.85V, 3.3V, 5V, and
Adjustable Versions
regulators with a dropout of 1.2V at 800mA of load
current. It has the same pin-out as Texas
Instruments' industry standard LM317.
Space Saving SOT-223 and WSON Packages
Current Limiting and Thermal Protection
Output Current 800mA
The LM1117-N is available in an adjustable version,
which can set the output voltage from 1.25V to 13.8V
with only two external resistors. In addition, it is also
available in five fixed voltages, 1.8V, 2.5V, 2.85V,
3.3V, and 5V.
Line Regulation 0.2% (Max)
Load Regulation 0.4% (Max)
Temperature Range
The LM1117-N offers current limiting and thermal
LM1117-N: 0°C to 125°C
shutdown. Its circuit includes
a zener trimmed
LM1117I: 40°C to 125°C
bandgap reference to assure output voltage accuracy
to within ±1%.
APPLICATIONS
The LM1117-N series is available in WSON, PFM,
SOT-223, TO-220, and TO-263 DDPAK packages. A
minimum of 10µF tantalum capacitor is required at
the output to improve the transient response and
stability.
2.85V Model for SCSI-2 Active Termination
Post Regulator for Switching DC/DC Converter
High Efficiency Linear Regulators
Battery Charger
Battery Powered Instrumentation
TYPICAL APPLICATION
Active Terminator for SCSI-2 Bus
Figure 1. Fixed Output Regulator
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
All trademarks are the property of their respective owners.
2
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Copyright © 2000–2013, Texas Instruments Incorporated
