型号: LM317T
厂商: STMicroelectronics STMicroelectronics
标准:
分类: 半导体集成电路 - IC
描述: linear voltage regulators 1.2-37v adj positive 1.5 amp output
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

LM317T的详细信息

Manufacturer: STMicroelectronics
Product Category: Linear Voltage Regulators
RoHS: Yes
Brand: STMicroelectronics
Output Type: Adjustable
Output Voltage: 1.2 V to 37 V
Output Current: 1.5 A
Load Regulation: 0.5 %
Input Voltage MAX: 40 V
Line Regulation: 0.04 % / V
Maximum Operating Temperature: + 125 C
Mounting Style: Through Hole
Package / Case: TO-220
Input Voltage MIN: 4.2 V
Minimum Operating Temperature: 0 C
Number of Outputs: 1
Packaging: Tube
Polarity: Positive
PSRR / Ripple Rejection - Typ: 80 dB
Series: LM317
Factory Pack Quantity: 1000
LM217, LM317
1.2 V to 37 V adjustable voltage regulators
Datasheet
-
production data
Description
The LM217, LM317 are monolithic integrated
circuits in TO-220, TO-220FP and D²PAK
packages intended for use as positive adjustable
voltage regulators. They are designed to supply
more than 1.5 A of load current with an output
voltage adjustable over a 1.2 to 37 V range. The
nominal output voltage is selected by means of a
resistive divider, making the device exceptionally
easy to use and eliminating the stocking of many
fixed regulators.
TO-220
TO-220FP
D²PAK
Features
Output voltage range: 1.2 to 37 V
Output current in excess of 1.5 A
0.1 % line and load regulation
Floating operation for high voltages
Complete series of protections: current limiting,
thermal shutdown and SOA control
Table 1. Device summary
Order codes
TO-220 (single gauge) TO-220 (double gauge)
D²PAK (tape and reel)
TO-220FP
LM217T
LM317T
LM317BT
LM217T-DG
LM317T-DG
LM217D2T-TR
LM317D2T-TR
LM317P
March 2014
DocID2154 Rev 19
1/25
This is information on a product in full production.
