Image LM331N/NOPB
型号: LM331N/NOPB
厂商: Texas Instruments Texas Instruments
标准:
分类: 半导体集成电路 - IC
描述: voltage to frequency & frequency to voltage prec vltg-TO-freq converter
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载2 >> 第三方平台下载 >>

LM331N/NOPB的详细信息

Manufacturer: Texas Instruments
Product Category: Voltage to Frequency & Frequency to Voltage
RoHS: Yes
Full Scale Frequency: 100 KHz
Linearity Error: +/- 0.14 %FSR
Supply Voltage - Max: 40 V
Supply Voltage - Min: 4 V
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
Mounting Style: Through Hole
Package / Case: MDIP
Packaging: Tube
Brand: Texas Instruments
Series: LM331
Factory Pack Quantity: 40
SNOSBI2B JUNE 1999REVISED MARCH 2013
Check for Samples: LM231, LM331
1
FEATURES
DESCRIPTION
The LM231/LM331 family of voltage-to-frequency
converters are ideally suited for use in simple low-
cost circuits for analog-to-digital conversion, precision
23
Ensured Linearity 0.01% max
Improved Performance in Existing Voltage-to-
Frequency Conversion Applications
frequency-to-voltage
integration, linear
conversion,
frequency modulation
long-term
or
Split or Single Supply Operation
demodulation, and many other functions. The output
when used as a voltage-to-frequency converter is a
pulse train at a frequency precisely proportional to the
applied input voltage. Thus, it provides all the
inherent advantages of the voltage-to-frequency
conversion techniques, and is easy to apply in all
standard voltage-to-frequency converter applications.
Further, the LM231A/LM331A attain a new high level
of accuracy versus temperature which could only be
Operates on Single 5V Supply
Pulse Output Compatible with All Logic Forms
Excellent Temperature Stability: ±50 ppm/°C
max
Low Power Consumption: 15 mW Typical at 5V
Wide Dynamic Range, 100 dB min at 10 kHz
Full Scale Frequency
Wide Range of Full Scale Frequency: 1 Hz to
100 kHz
attained
with
expensive
voltage-to-frequency
modules. Additionally the LM231/331 are ideally
suited for use in digital systems at low power supply
voltages and can provide low-cost analog-to-digital
conversion in microprocessor-controlled systems.
And, the frequency from a battery powered voltage-
to-frequency converter can be easily channeled
through a simple photo isolator to provide isolation
against high common mode levels.
Low Cost
The LM231/LM331 utilize
a
new temperature-
compensated band-gap reference circuit, to provide
excellent accuracy over the full operating temperature
range, at power supplies as low as 4.0V. The
precision timer circuit has low bias currents without
degrading the quick response necessary for 100 kHz
voltage-to-frequency conversion. And the output are
capable of driving 3 TTL loads, or a high voltage
output up to 40V, yet is short-circuit-proof against
VCC
.
CONNECTION DIAGRAM
Figure 1. Plastic Dual-In-Line Package (PDIP)
See Package Number P (R-PDIP-T8)
1
