Image LM339N
型号: LM339N
厂商: Fairchild Semiconductor Fairchild Semiconductor
标准:
分类: 半导体集成电路 - IC
描述: comparator ics quad comparator
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载2 >> 第三方平台下载 >>

LM339N的详细信息

Manufacturer: Fairchild Semiconductor
Product Category: Comparator ICs
RoHS: Yes
Comparator Type: Differential
Number of Channels: 4 Channel
Output Type: Open Collector
Supply Voltage - Max: 36 V
Supply Voltage - Min: 18 V
Input Bias Current - Max: 250 nA
Offset Voltage - Max: 5 mV
Supply Current - Max: 2 mA
Maximum Operating Temperature: + 70 C
Mounting Style: Through Hole
Package / Case: DIP-14
Packaging: Tube
Brand: Fairchild Semiconductor
Maximum Power Dissipation: 570 mW
Minimum Operating Temperature: 0 C
Output Current - Typ: 18 mA
Response Time: 1.3 us
Series: LM339
Factory Pack Quantity: 25
Part # Aliases: LM339N_NL
Unit Weight: 1.620 g
www.fairchildsemi.com
LM339/LM339A, LM239A, LM2901
Quad Comparator
Features
Description
• Single or Dual Supply Operation
• Wide Range of Supply Voltage
The LM339/LM339A ,LM239A, LM2901 consist of four
independent voltage comparators designed to operate from
single power supply over a wide voltage range.
LM2901, LM339/LM339A, LM239A: 2 ~ 36V (or ±1 ~
±18V)
• Low Supply Current Drain 800μA Typ.
• Open Collector Outputs for Wired and Connectors
• Low Input Bias Current 25nA Typ.
• Low Input Offset Current ±2.3nA Typ.
• Low Input Offset Voltage ±1.4mV Typ.
• Input Common Mode Voltage Range Includes Ground.
• Low Output Saturation Voltage
14-DIP
1
14-SOP
• Output Compatible With TTL, DTL and MOS Logic
System
1
Internal Block Diagram
14
OUT3
OUT4
1
2
OUT2
OUT1
13
12
11
10
GND
V
3
4
CC
-
+
-
+
IN4(+)
IN1(-)
IN1(+)
IN4(-)
5
IN3(+)
IN3(-)
IN2(-)
9
8
6
7
+
-
+
-
IN2(+)
Rev. 1.0.5
©2012 Fairchild Semiconductor Corporation
