Image LM358P
型号: LM358P
厂商: Texas Instruments Texas Instruments
标准:
分类: 半导体集成电路 - IC
描述: operational amplifiers - Op amps dual Op amp
PDF: 预览
报错 收藏

LM358P的详细信息

Manufacturer: Texas Instruments
Product Category: Operational Amplifiers - Op Amps
RoHS: Yes
Amplifier Type: High Gain Amplifier
Gain Bandwidth Product: 0.7 MHz
Number of Channels: 2 Channel
Common Mode Rejection Ratio - Min: 65 dB
Input Offset Voltage: 7 mV
Input Bias Current - Max: 250 nA
Operating Supply Voltage: 3 V to 32 V, +/- 1.5 V to +/- 16 V
Mounting Style: Through Hole
Package / Case: PDIP-8
Slew Rate: 0.3 V/us
Shutdown: No Shutdown
Output Current: 30 mA
Maximum Operating Temperature: + 70 C
Packaging: Tube
Brand: Texas Instruments
Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V
Input Referred Voltage Noise: 40 nV
Maximum Dual Supply Voltage: +/- 16 V
Minimum Dual Supply Voltage: +/- 1.5 V
Minimum Operating Temperature: 0 C
Series: LM358
Factory Pack Quantity: 50
Supply Current: 1.2 mA
Technology: Bipolar
Unit Weight: 440.400 mg
SLOS068S JUNE 1976REVISED MAY 2013
1
FEATURES
DESCRIPTION
These devices consist of two independent, high-gain
frequency-compensated operational amplifiers
Wide Supply Ranges
Single Supply: 3 V to 32 V (26 V for
LM2904)
designed to operate from a single supply over a wide
range of voltages. Operation from split supplies also
is possible if the difference between the two supplies
is 3 V to 32 V (3 V to 26 V for the LM2904), and VCC
is at least 1.5 V more positive than the input
common-mode voltage. The low supply-current drain
is independent of the magnitude of the supply
voltage.
Dual Supplies: ±1.5 V to ±16 V (±13 V for
LM2904)
Low Supply-Current Drain, Independent of
Supply Voltage: 0.7 mA Typ
Wide Unity Gain Bandwidth: 0.7MHz
Common-Mode Input Voltage Range Includes
Ground, Allowing Direct Sensing Near Ground
Applications include transducer amplifiers, dc
amplification blocks, and all the conventional
operational amplifier circuits that now can be
implemented more easily in single-supply-voltage
systems. For example, these devices can be
operated directly from the standard 5-V supply used
in digital systems and easily can provide the required
interface electronics without additional ±5-V supplies.
Low Input Bias and Offset Parameters
Input Offset Voltage: 3 mV Typ
A Versions: 2 mV Typ
Input Offset Current: 2 nA Typ
Input Bias Current: 20 nA Typ
A Versions: 15 nA Typ
Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage: 32 V (26 V for
LM2904)
Open-Loop Differential Voltage Gain: 100dB
Typ
Internal Frequency Compensation
On Products Compliant to MIL-PRF-38535,
All Parameters Are Tested Unless Otherwise
Noted. On All Other Products, Production
Processing Does Not Necessarily Include
Testing of All Parameters.
LM158, LM158A . . . FK Package
(Top View)
LM158, LM158A . . . JG Package
LM258, LM258A . . . D, DGK, or P Package
LM358 . . . D, DGK, P, PS, or PW Package
LM358A . . . D, DGK, P, or PW Package
LM2904 . . . D, DGK, P, PS, or PW Package
(Top View)
3
2
1
20 19
18
NC
NC
1IN−
NC
4
5
6
7
8
17
16
15
14
2OUT
NC
1OUT
1IN−
1IN+
GND
VCC
1
2
3
4
8
7
6
5
2OUT
2IN−
2IN+
2IN−
NC
1IN+
NC
9 10 11 12 13
NC No internal connection
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Copyright © 1976–2013, Texas Instruments Incorporated
