型号: LM393
厂商: Texas Instruments Texas Instruments
标准:
分类: 半导体
描述: dual differential comparators
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >>

LM393的详细信息

Feature: Dual Differential Comparator
ꢀ ꢁꢂ ꢃ ꢄ ꢅ ꢀ ꢁꢆ ꢃ ꢄ ꢅ ꢀ ꢁ ꢆ ꢃ ꢄ ꢇ
ꢀ ꢁꢄ ꢃ ꢄ ꢅ ꢀ ꢁꢄ ꢃ ꢄ ꢇ ꢅ ꢀ ꢁꢆ ꢃ ꢈ ꢄ ꢅ ꢀ ꢁ ꢆ ꢃ ꢈ ꢄ ꢉ
ꢊ ꢋ ꢇ ꢀ ꢊ ꢌ ꢍꢍ ꢎ ꢏ ꢎ ꢐ ꢑ ꢌ ꢇ ꢀ ꢒ ꢓ ꢁ ꢔꢇ ꢏꢇꢑꢓ ꢏꢕ
SLCS005S − JUNE 1976 − REVISED OCTOBER 2004
LM193 . . . D OR JG PACKAGE
LM293 . . . D, DGK, OR P PACKAGE
LM293A . . . D OR DGK PACKAGE
D
D
Single Supply or Dual Supplies
Wide Range of Supply Voltage
− Max Rating . . . 2 V to 36 V
− Tested to 30 V . . . Non-V Devices
− Tested to 32 V . . . V-Suffix Devices
LM393, LM393A . . . D, DGK, P, PS, OR PW PACKAGE
LM2903 . . . D, DGK, P, PS, OR PW PACKAGE
(TOP VIEW)
D
Low Supply-Current Drain Independent of
Supply Voltage . . . 0.4 mA Typ Per
Comparator
1OUT
1IN−
1IN+
GND
V
CC
1
2
3
4
8
7
6
5
2OUT
2IN−
2IN+
D
D
Low Input Bias Current . . . 25 nA Typ
Low Input Offset Current . . . 3 nA Typ
(LM193)
LM193 . . . FK PACKAGE
(TOP VIEW)
D
Low Input Offset Voltage . . . 2 mV Typ
D
Common-Mode Input Voltage Range
Includes Ground
D
Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage . . . ±36 V
Low Output Saturation Voltage
3
2
1 20 19
18
NC
NC
1IN−
NC
4
5
6
7
8
D
2OUT
NC
17
16
15
14
D
Output Compatible With TTL, MOS, and
CMOS
2IN−
NC
1IN+
NC
9 10 11 12 13
description/ordering information
These devices consist of two independent voltage
comparators that are designed to operate from a
single power supply over a wide range of voltages.
Operation from dual supplies also is possible as
long as the difference between the two supplies is
NC − No internal connection
2 V to 36 V, and V
is at least 1.5 V more positive than the input common-mode voltage. Current drain is
CC
independent of the supply voltage. The outputs can be connected to other open-collector outputs to achieve
wired-AND relationships.
The LM193 is characterized for operation from −55°C to 125°C. The LM293 and LM293A are characterized for
operation from −25°C to 85°C. The LM393 and LM393A are characterized for operation from 0°C to 70°C. The
LM2903 is characterized for operation from −40°C to 125°C.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
