Image LM7805
型号: LM7805
厂商: Fairchild Semiconductor Fairchild Semiconductor
标准:
分类: 半导体
描述: 3-terminal 1A positive voltage regulator
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >>

LM7805的详细信息

  • 亲,您要的详细信息都在下载文档里了!

    本地下载

www.fairchildsemi.com
MC78XX/LM78XX/MC78XXA
3-Terminal 1A Positive Voltage Regulator
Features
Description
• Output Current up to 1A
• Output Voltages of 5, 6, 8, 9, 10, 12, 15, 18, 24V
• Thermal Overload Protection
The MC78XX/LM78XX/MC78XXA series of three
terminal positive regulators are available in the
TO-220/D-PAK package and with several fixed output
voltages, making them useful in a wide range of
• Short Circuit Protection
• Output Transistor Safe Operating Area Protection
applications. Each type employs internal current limiting,
thermal shut down and safe operating area protection,
making it essentially indestructible. If adequate heat sinking
is provided, they can deliver over 1A output current.
Although designed primarily as fixed voltage regulators,
these devices can be used with external components to
obtain adjustable voltages and currents.
TO-220
1
D-PAK
1
1. Input 2. GND 3. Output
Internal Block Digram
Rev. 1.0.1
©2001 Fairchild Semiconductor Corporation
