型号: LT1684IS#TRPBF
厂商: Linear Technology Linear Technology
标准:
分类: 集成电路接口 - 电信
描述: IC ring tone generator 14-soic
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >>

LT1684IS#TRPBF的详细信息

Datasheets:
LT1684:
Product Photos:
14-SOIC:
Standard Package : 2,500
Category: Integrated Circuits (ICs)
Family: Interface - Telecom
Series: -
Packaging : Tape & Reel (TR)
Function: Tone Generator
Interface: -
Number of Circuits: 1
Voltage - Supply: -
Current - Supply: -
Power (Watts): -
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: 14-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 14-SOIC
Includes: -
For Use With: DC192A-ND - EVAL BOARD RING TONE GEN LT1684
LT1684
Micropower
Ring Tone Generator
U
FEATURES
DESCRIPTIO
Allows Dynamic Control of Output Frequency,
The LT®1684 is a telecommunication ring tone generator.
The IC takes a user-generated pulse width modulated
(PWM) input and converts it to a high voltage sine wave
suitable for telephone ringing applications.
Cadence, Amplitude and DC Offset
Active Tracking Supply Configuration Allows Linear
Generation of Ring Tone Signal
No High Voltage Post-Filtering Required
The LT1684 receives capacitor-isolated differential PWM
input signals encoded with desired ring output cadence,
frequency, and amplitude information. The LT1684 nor-
malizes the pulse amplitude to ±1.25V for an accurate
signal voltage reference. The cadence, frequency and
amplitude information is extracted using a multiple-
pole active filter/amplifier, producing the output ring tone
signal.
Capacitive Isolation Eliminates Optocouplers
Low Distortion Output Meets International
PTT Requirements
Differential Input Signal for Noise Immunity
User Adjustable Active Output Current Limit
Powered Directly From High Voltage Ringer
Supply—No Additional Supplies Necessary
Supply Current: <1mA
2% Signal Amplitude Reference
The LT1684 uses its own ring tone output as a reference
for generating local supply rails using complementary
high voltage external MOSFETs as dynamic level-shifting
devices. This “active tracking” supply mode of operation
allows linear generation of the high voltage ring tone
signal, reducing the need for large high voltage filtering
elements.
Available in 14-Pin SO and DIP Packages
U
APPLICATIO S
Wireless Local Loop Telephones
Key System/PBX Equipment
, LTC and LT are registered trademarks of Linear Technology Corporation.
Fiber to the Curb Telecom Equipment
U
TYPICAL APPLICATIO
Electrically Isolated Ring Tone Generator
DC
100V
PWM
ISOLATION
CONTROLLER
6.8nF
100k
10k
100pF
100pF
+
P1
µC
IN A
IN B
GATE
V
IRF610
100
FB1
10k
+
+
P2
LT1684
1N4001
LIM
OUT
+
100pF
20pF
AT
REF
RING TONE
OUTPUT
±100mA
CAPABILITY
(
)
BG
COMP1
OUT
0.1µF
3k
1N5817
6.8nF
COMP2
2k
5k
AMPIN
LIM
V
4700pF
300k
100Ω
GATE
IRF9610
1µF
100k
–100V
FB1: FERRONICS FMB1601
(716) 388-1020
1684 TA01
