LTC4355
Positive High Voltage
Ideal Diode-OR with Input Supply
and Fuse Monitors
FeaTures
DescripTion
TheLTC®4355isapositivevoltageidealdiode-ORcontroller
that drives two external N-channel MOSFETs. Forming the
diode-OR with N-channel MOSFETs instead of Schottky
diodes reduces power consumption, heat dissipation and
PC board area.
Replaces Power Schottky Diodes
Controls N-Channel MOSFETs
0.5µs Turn-Off Time Limits Peak Fault Current
Wide Operating Voltage Range: 9V to 80V
Smooth Switchover without Oscillation
No Reverse DC Current
With the LTC4355, power sources can easily be ORed
together to increase total system reliability. The LTC4355
can diode-OR two positive supplies or the return paths of
two negative supplies, such as in a 48V system.
Monitors V , Fuse, and MOSFET Diode
IN
Available in 14-Lead (4mm × 3mm) DFN and
16-Lead SO Packages
In the forward direction the LTC4355 controls the voltage
dropacrosstheMOSFETtoensuresmoothcurrenttransfer
from one path to the other without oscillation. If a power
source fails or is shorted, fast turnoff minimizes reverse
current transients.
applicaTions
High Availability Systems
AdvancedTCA® (ATCA) Systems
+48V and –48V Distributed Power Systems
Telecom Infrastructure
Power fault detection indicates if the input supplies are
not in regulation, the inline fuses are blown, or the
voltages across the MOSFETs are greater than the fault
threshold.
, LT, LTC and LTM are registered trademarks of Linear Technology Corporation.
All other trademarks are the property of their respective owners.
Typical applicaTion
+48V Diode-OR
Power Dissipation vs Load Current
7A
7A
FDB3632
TO
V
V
= +48V
= +48V
IN1
IN2
6
LOAD
FDB3632
5
22k
22k
22k
DIODE (MBR10100)
4
3
340k
340k
22k
22k
IN1 GATE1 IN2 GATE2 OUT
POWER
SAVED
MON1
VDSFLT
FUSEFLT1
FUSEFLT2
PWRFLT1
PWRFLT2
LTC4355
GND
2
1
0
SET
MON2
FET (FDB3632)
12.7k
12.7k
GREEN LEDs
PANASONIC LN1351C
0
2
4
6
8
10
GND
CURRENT (A)
4355 TA01
4355 TA02
4355fa
