型号: MAX3232ESE+
厂商: Maxim Integrated Maxim Integrated
标准:
分类: 半导体集成电路 - IC
描述: RS-232 interface IC 3-5.5V 235kbps transceiver
PDF: 预览
报错 收藏

MAX3232ESE+的详细信息

Manufacturer: Maxim Integrated
Product Category: RS-232 Interface IC
RoHS: Yes
Function: Transceiver
Data Rate: 235 kbps
Number of Drivers: 2
Number of Receivers: 2
Operating Supply Voltage: 3 V to 5.5 V
Supply Current: 1 mA
Shutdown: No
Maximum Operating Temperature: + 85 C
Mounting Style: SMD/SMT
Package / Case: SO-16 Narrow
Packaging: Tube
Brand: Maxim Integrated
Minimum Operating Temperature: - 40 C
Number of I/Os: 8
Operating Temperature Range: - 40 C to + 85 C
Propagation Delay Time ns: 0.3 us
Series: MAX3232
Factory Pack Quantity: 50
Part # Aliases: MAX3232
19-0273; Rev 7; 1/07
3.0V to 5.5V, Low-Power, up to 1Mbps, True RS-232
Transceivers Using Four 0.1µF External Capacitors
7/MAX3241*
________________General Description
__Next Generation Device Features
For Smaller Packaging:
The MAX3222/MAX3232/MAX3237/MAX3241 trans-
ceivers have a proprietary low-dropout transmitter out-
put stage enabling true RS-232 performance from a
3.0V to 5.5V supply with a dual charge pump. The
devices require only four small 0.1µF external charge-
pump capacitors. The MAX3222, MAX3232, and
MAX3241 are guaranteed to run at data rates of
120kbps while maintaining RS-232 output levels. The
MAX3237 is guaranteed to run at data rates of 250kbps
in the normal operating mode and 1Mbps in the
MegaBaud™ operating mode, while maintaining RS-232
output levels.
MAX3228E/MAX3229E: +2.5V to +5.5V RS-232
Transceivers in UCSP™
For Integrated ESD Protection:
MAX3222E/MAX3232E/MAX3237E/MAX3241E*/
MAX3246E: ± 15kV ESD-Protectedꢀ Doꢁn to 1ꢂnAꢀ
3.ꢂV to 5.5Vꢀ Up to 1Mbpsꢀ True RS-232
Transceivers
For Loꢁ-Voltage or Data Cable Applications:
MAX338ꢂE/MAX3381E: +2.35V to +5.5Vꢀ 1μAꢀ
2Tx/2Rx RS-232 Transceivers ꢁith ± 15kV
ESD-Protected I/O and Logic Pins
The MAX3222/MAX3232 have 2 receivers and 2
drivers. The MAX3222 features a 1µA shutdown mode
that reduces power consumption and extends battery
life in portable systems. Its receivers remain active in
shutdown mode, allowing external devices such as
modems to be monitored using only 1µA supply cur-
rent. The MAX3222 and MAX3232 are pin, package,
and functionally compatible with the industry-standard
MAX242 and MAX232, respectively.
_______________Ordering Information
PKG
PART
TEMP RANGE PIN-PACKAGE
CODE
U20+2
A20+1
W18+1
MAX3222CUP+ 0°C to +70°C
MAX3222CAP+ 0°C to +70°C
MAX3222CWN+ 0°C to +70°C
MAX3222CPN+ 0°C to +70°C
20 TSSOP
20 SSOP
18 SO
The MAX3241 is a complete serial port (3 drivers/
5 receivers) designed for notebook and subnotebook
computers. The MAX3237 (5 drivers/3 receivers) is ideal
for fast modem applications. Both these devices feature
a shutdown mode in which all receivers can remain
active while using only 1µA supply current. Receivers R1
(MAX3237/MAX3241) and R2 (MAX3241) have extra out-
puts in addition to their standard outputs. These extra
outputs are always active, allowing external devices
such as a modem to be monitored without forward bias-
18 Plastic Dip P18+5
+Denotes lead-free package.
Ordering Information continued at end of data sheet.
ing the protection diodes in circuitry that may have V
completely removed.
CC
_________________Pin Configurations
The MAX3222, MAX3232, and MAX3241 are available
in space-saving TSSOP and SSOP packages.
TOP VIEW
+
EN
C1+
V+
1
2
3
4
5
6
7
8
9
SHDN
18
17
16
15
14
13
12
11
10
V
________________________Applications
Notebook, Subnotebook, and Palmtop Computers
High-Speed Modems
CC
GND
MAX3222
T1OUT
R1IN
C1-
C2+
C2-
Battery-Powered Equipment
Hand-Held Equipment
R1OUT
T1IN
V-
Peripherals
T2IN
T2OUT
R2IN
Printers
R2OUT
DIP/SO
Typical Operating Circuits appear at end of data sheet.
Pin Configurations continued at end of data sheet.
MegaBaud and UCSP are trademarks of Maxim Integrated Products, Inc.
*Covered by U.S. Patent numbers 4,636,930; 4,679,134; 4,777,577; 4,797,899; 4,809,152; 4,897,774; 4,999,761; and other patents pending.
________________________________________________________________ Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
