19-0333; Rev 0; 12/94
3 .3 V-P o w e re d , 1 0 Mb p s a n d S le w -Ra t e -Lim it e d
Tru e RS -4 8 5 /RS -4 2 2 Tra n s c e ive rs
5680/MAX3491
_______________Ge n e ra l De s c rip t io n
____________________________Fe a t u re s
The MAX3483, MAX3485, MAX3486, MAX3488,
MAX3490, and MAX3491 are 3.3V, low-power trans -
ceivers for RS-485 and RS-422 communication. Each
p a rt c onta ins one d rive r a nd one re c e ive r. The
MAX3483 and MAX3488 feature slew-rate-limited dri-
vers that minimize EMI and reduce reflections caused
by improperly terminated cables, allowing error-free
data transmission at data rates up to 250kbps. The par-
tia lly s le w-ra te -limite d MAX3486 tra ns mits up to
2.5Mb p s . The MAX3485, MAX3490, a nd MAX3491
transmit at up to 10Mbps.
Operate from a Single 3.3V Supply—
No Charge Pump!
Interoperable with +5V Logic
8ns Max Skew (MAX3485/MAX3490/MAX3491)
Slew-Rate Limited for Errorless Data Transmission
(MAX3483/MAX3488)
2nA Low-Current Shutdown Mode
(MAX3483/MAX3485/MAX3486/MAX3491)
-7V to +12V Common-Mode Input Voltage Range
Allows up to 32 Transceivers on the Bus
Drivers are short-circuit current limited and are protect-
ed against excessive power dissipation by thermal
shutdown circuitry that places the driver outputs into a
high-impedance state. The receiver input has a fail-safe
fe a ture tha t g ua ra nte e s a log ic -hig h outp ut if b oth
inputs are open circuit.
Full-Duplex and Half-Duplex Versions Available
Industry Standard 75176 Pinout
(MAX3483/MAX3485/MAX3486)
The MAX3488, MAX3490, and MAX3491 feature full-
duplex communication, while the MAX3483, MAX3485,
and MAX3486 are designed for half-duplex communi-
cation.
Current-Limiting and Thermal Shutdown for
Driver Overload Protection
______________Ord e rin g In fo rm a t io n
________________________Ap p lic a t io n s
PART
TEMP. RANGE
0°C to +70°C
0°C to +70°C
0°C to +70°C
-40°C to +85°C
-40°C to +85°C
0°C to +70°C
0°C to +70°C
0°C to +70°C
-40°C to +85°C
-40°C to +85°C
PIN-PACKAGE
8 Plastic DIP
8 SO
Low-Power RS-485/RS-422 Transceivers
Telecommunications
MAX3483CPA
MAX3483CSA
MAX3483C/D
MAX3483EPA
MAX3483ESA
MAX3485CPA
MAX3485CSA
MAX3485C/D
MAX3485EPA
MAX3485ESA
Transceivers for EMI-Sensitive Applications
Industrial-Control Local Area Networks
Dice*
8 Plastic DIP
8 SO
8 Plastic DIP
8 SO
Dice*
8 Plastic DIP
8 SO
Ordering Information continued at end of data sheet.
* Contact factory for for dice specifications.
______________________________________________________________S e le c t io n Ta b le
GUARANTEED
DATA RATE
(Mbps)
SUPPLY
VOLTAGE
(V)
DRIVER/
RECEIVER
ENABLE
SHUTDOWN
CURRENT
(nA)
PART
NUMBER
HALF/FULL
DUPLEX
SLEW-RATE
LIMITED
PIN
COUNT
MAX3483
MAX3485
MAX3486
MAX3488
MAX3490
MAX3491
0.25
10
Half
Half
Half
Full
Full
Full
Yes
No
Yes
Yes
Yes
No
2
2
8
8
2.5
0.25
10
Yes
Yes
No
2
8
3.0 to 3.6
2
8
No
8
10
No
Yes
14
________________________________________________________________ Maxim Integrated Products
1
Ca ll t o ll fre e 1 -8 0 0 -9 9 8 -8 8 0 0 fo r fre e s a m p le s o r lit e ra t u re .
