型号: MAX809
厂商: ON Semiconductor ON Semiconductor
分类: 集成电路
描述: 3-pin microprocessor reset monitors
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >>

MAX809的详细信息

  • 亲,您要的详细信息都在下载文档里了!

    本地下载

MAX809 Series,
MAX810 Series
Very Low Supply Current
3-Pin Microprocessor
Reset Monitors
The MAX809 and MAX810 are cost–effective system supervisor
circuits designed to monitor VCC in digital systems and provide a reset
signal to the host processor when necessary. No external components
are required.
The reset output is driven active within 10 µsec of VCC falling
through the reset voltage threshold. Reset is maintained active for a
minimum of 140 msec after VCC rises above the reset threshold. The
MAX810 has an active–high RESET output while the MAX809 has
an active–low RESET output. The output of the MAX809 is
guaranteed valid down to VCC = 1.0 V. Both devices are available in a
SOT–23 package.
The MAX809/810 are optimized to reject fast transient glitches on
the VCC line. Low supply current of 1.0 µA (VCC = 3.2 V) makes these
devices suitable for battery powered applications.
3
3
SOT–23
(TO–236)
CASE 318
xxxm
1
1
2
2
3
See specific device marking
information on page 8.
xxyw
1
2
xx, xxx = Specific Device Code
Features
m
y
= Date Code
= Year
Precision VCC Monitor for 2.5 V, 3.0 V, 3.3 V, and 5.0 V Supplies
Precision Monitoring Voltages from 1.6 V to 4.9 V Available
in 100 mV Steps
w
= Work Week
140 msec Guaranteed Minimum RESET Output Duration
PIN CONFIGURATION
RESET Output Guaranteed to VCC = 1.0 V
Low Supply Current
1
GND
VCC Transient Immunity
Small SOT–23 Package
V
CC
3
No External Components
RESET**
(RESET)***
Wide Operating Temperature: –40°C to 105°C
Typical Applications
2
Computers
Embedded Systems
Battery Powered Equipment
Critical µP Power Supply Monitoring
SOT–23*
(Top View)
NOTE: *SOT–23 is equivalent to JEDEC (TO–236)
**RESET is for MAX809
***RESET is for MAX810
V
CC
ORDERING INFORMATION
Device
Package
Shipping
V
CC
V
CC
PROCESSOR
MAX809xTR
SOT–23
3000 Tape/Reel
MAX809/810
RESET
INPUT
RESET
RESET
MAX809SNxxxT1
MAX810xTR
SOT–23
SOT–23
3000 Tape/Reel
3000 Tape/Reel
GND
GND
NOTE: The “x” and “xxx” denotes a suffix for V voltage
cc
threshold options – see page 8 for more details.
DEVICE MARKING INFORMATION
See general marking information in the device marking
section on page 8 of this data sheet.
Figure 1. Typical Application Diagram
Semiconductor Components Industries, LLC, 2002
1
Publication Order Number:
January, 2002 – Rev. 4
MAX809S/D
