Image MK60DN512ZVLQ10
型号: MK60DN512ZVLQ10
厂商: Freescale Semiconductor Freescale Semiconductor
标准:
分类: 半导体集成电路 - IC
描述: arm microcontrollers - mcu kinetis cortex M4 512k enet
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

MK60DN512ZVLQ10的详细信息

Manufacturer: Freescale Semiconductor
Product Category: ARM Microcontrollers - MCU
RoHS: Yes
Core: ARM Cortex M4
Data Bus Width: 32 bit
Maximum Clock Frequency: 100 MHz
Program Memory Size: 512 kB
Data RAM Size: 128 kB
Operating Supply Voltage: 1.71 V to 3.6 V
Maximum Operating Temperature: + 105 C
Package / Case: LQFP-144
Mounting Style: SMD/SMT
Brand: Freescale Semiconductor
Data RAM Type: RAM
Interface Type: CAN, I2C, SPI, UART, USB
Minimum Operating Temperature: - 40 C
Number of Programmable I/Os: 2
Number of Timers: 2
Packaging: Tray
Processor Series: K60
Program Memory Type: Flash
Series: K60_100
Factory Pack Quantity: 60
Tradename: Kinetis
Unit Weight: 1.319 g
Document Number: K60P144M100SF2
Rev. 7, 02/2013
Freescale Semiconductor
Data Sheet: Technical Data
K60P144M100SF2
K60 Sub-Family Data Sheet
Supports the following:
MK60DN256ZVLQ10,
MK60DX256ZVLQ10,
MK60DN512ZVLQ10,
MK60DN256ZVMD10,
MK60DX256ZVMD10,
MK60DN512ZVMD10
Features
Security and integrity modules
– Hardware CRC module to support fast cyclic
redundancy checks
– Hardware random-number generator
– Hardware encryption supporting DES, 3DES, AES,
MD5, SHA-1, and SHA-256 algorithms
– 128-bit unique identification (ID) number per chip
Operating Characteristics
– Voltage range: 1.71 to 3.6 V
– Flash write voltage range: 1.71 to 3.6 V
– Temperature range (ambient): -40 to 105°C
Performance
– Up to 100 MHz ARM Cortex-M4 core with DSP
instructions delivering 1.25 Dhrystone MIPS per
MHz
Human-machine interface
– Low-power hardware touch sensor interface (TSI)
– General-purpose input/output
Memories and memory interfaces
– Up to 512 KB program flash memory on non-
FlexMemory devices
Analog modules
– Two 16-bit SAR ADCs
– Up to 256 KB program flash memory on
FlexMemory devices
– Programmable gain amplifier (PGA) (up to x64)
integrated into each ADC
– Up to 256 KB FlexNVM on FlexMemory devices
– 4 KB FlexRAM on FlexMemory devices
– Up to 128 KB RAM
– Serial programming interface (EzPort)
– FlexBus external bus interface
– Two 12-bit DACs
– Three analog comparators (CMP) containing a 6-bit
DAC and programmable reference input
– Voltage reference
Timers
Clocks
– Programmable delay block
– Eight-channel motor control/general purpose/PWM
timer
– Two 2-channel quadrature decoder/general purpose
timers
– 3 to 32 MHz crystal oscillator
– 32 kHz crystal oscillator
– Multi-purpose clock generator
System peripherals
– IEEE 1588 timers
– Multiple low-power modes to provide power
optimization based on application requirements
– Memory protection unit with multi-master
protection
– Periodic interrupt timers
– 16-bit low-power timer
– Carrier modulator transmitter
– Real-time clock
– 16-channel DMA controller, supporting up to 63
request sources
– External watchdog monitor
– Software watchdog
– Low-leakage wakeup unit
Freescale reserves the right to change the detail specifications as may be
required to permit improvements in the design of its products.
© 2011–2013 Freescale Semiconductor, Inc.
