Image MMBT3904
型号: MMBT3904
厂商: Fairchild Semiconductor Fairchild Semiconductor
标准:
分类: 半导体分离式半导体
描述: transistors bipolar - bjt sot-23 npn gen pur
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

MMBT3904的详细信息

Manufacturer: Fairchild Semiconductor
Product Category: Transistors Bipolar - BJT
RoHS: Yes
Configuration: Single
Transistor Polarity: NPN
Collector- Base Voltage VCBO: 60 V
Collector- Emitter Voltage VCEO Max: 40 V
Emitter- Base Voltage VEBO: 6 V
Collector-Emitter Saturation Voltage: 0.3 V
Maximum DC Collector Current: 0.2 A
Gain Bandwidth Product fT: 300 MHz
Maximum Operating Temperature: + 150 C
Mounting Style: SMD/SMT
Package / Case: SOT-23
Brand: Fairchild Semiconductor
Continuous Collector Current: 0.2 A
DC Collector/Base Gain hfe Min: 100
DC Current Gain hFE Max: 300
Maximum Power Dissipation: 625 mW
Minimum Operating Temperature: - 55 C
Packaging: Reel
Series: MMBT3904
Factory Pack Quantity: 3000
Part # Aliases: MMBT3904_NL
Unit Weight: 60 mg
October 2011
2N3904 / MMBT3904 / PZT3904
NPN General Purpose Amplifier
Features
• This device is designed as a general purpose amplifier and switch.
• The useful dynamic range extends to 100 mA as a switch and to 100 MHz as an amplifier.
PZT3904
2N3904
MMBT3904
C
C
E
E
C
B
TO-92
SOT-23
B
SOT-223
Mark:1A
EBC
Absolute Maximum Ratings* T = 25°C unless otherwise noted
a
Symbol
Parameter
Collector-Emitter Voltage
Value
Units
V
V
V
V
40
60
CEO
CBO
EBO
Collector-Base Voltage
V
Emitter-Base Voltage
6.0
V
I
Collector Current - Continuous
Operating and Storage Junction Temperature Range
200
mA
°C
C
T T
-55 to +150
J, stg
* These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
NOTES:
1) These ratings are based on a maximum junction temperature of 150 degrees C.
2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle
operations.
Thermal Characteristics T = 25°C unless otherwise noted
a
Max.
Symbol
Parameter
Units
2N3904
*MMBT3904
**PZT3904
Total Device Dissipation
625
5.0
350
2.8
1,000
8.0
mW
mW/°C
P
D
Derate above 25°C
R
R
Thermal Resistance, Junction to Case
Thermal Resistance, Junction to Ambient
83.3
200
°C/W
°C/W
θJC
357
125
θJA
* Device mounted on FR-4 PCB 1.6" X 1.6" X 0.06".
** Device mounted on FR-4 PCB 36 mm X 18 mm X 1.5 mm; mounting pad for the collector lead min. 6 cm .
2
© 2011 Fairchild Semiconductor Corporation
2N3904 / MMBT3904 / PZT3904 Rev. B0
www.fairchildsemi.com
1
