型号: MMBT4401
厂商: Fairchild Semiconductor Fairchild Semiconductor
标准:
分类: 半导体分离式半导体
描述: transistors bipolar - bjt sot-23 npn gen pur
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

MMBT4401的详细信息

Manufacturer: Fairchild Semiconductor
Product Category: Transistors Bipolar - BJT
RoHS: Yes
Configuration: Single
Transistor Polarity: NPN
Collector- Base Voltage VCBO: 60 V
Collector- Emitter Voltage VCEO Max: 40 V
Emitter- Base Voltage VEBO: 6 V
Collector-Emitter Saturation Voltage: 0.75 V
Maximum DC Collector Current: 0.6 A
Gain Bandwidth Product fT: 250 MHz
Maximum Operating Temperature: + 150 C
Mounting Style: SMD/SMT
Package / Case: SOT-23
Brand: Fairchild Semiconductor
Continuous Collector Current: 0.6 A
DC Collector/Base Gain hfe Min: 100
DC Current Gain hFE Max: 300
Maximum Power Dissipation: 350 mW
Minimum Operating Temperature: - 55 C
Packaging: Reel
Series: MMBT4401
Factory Pack Quantity: 3000
Part # Aliases: MMBT4401_NL
Unit Weight: 60 mg
2N4401
MMBT4401
C
E
TO-92
C
B
SOT-23
Mark: 2X
B
E
NPN General Pupose Amplifier
This device is designed for use as a medium power amplifier and
switch requiring collector currents up to 500 mA.
Absolute Maximum Ratings*
TA= 25°C unless otherwise noted
Symbol
Parameter
Value
Units
VCEO
VCBO
VEBO
IC
Collector-Emitter Voltage
40
60
V
V
Collector-Base Voltage
Emitter-Base Voltage
6.0
V
Collector Current - Continuous
Operating and Storage Junction Temperature Range
600
mA
-55 to +150
C
°
TJ, Tstg
*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
NOTES:
1) These ratings are based on a maximum junction temperature of 150 degrees C.
2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.
Thermal Characteristics
TA= 25°C unless otherwise noted
Symbol
Characteristic
Max
Units
2N4401
*MMBT4401
PD
Total Device Dissipation
Derate above 25 C
625
5.0
350
2.8
mW
mW/ C
°
°
Thermal Resistance, Junction to Case
83.3
Rθ
C/W
°
JC
Thermal Resistance, Junction to Ambient
200
357
Rθ
C/W
°
JA
*Device mounted on FR-4 PCB 1.6" X 1.6" X 0.06."
2001 Fairchild Semiconductor Corporation
2N4401/MMBT4401, Rev A
