ON Semiconductor
NSBC144WDXV6T1G的详细信息
| Datasheets： | |
|---|---|
| MUN5237DW1, NSBC144WDxx： | |
| Standard Package ： | 4,000 |
| Category： | Discrete Semiconductor Products |
| Family： | Transistors (BJT) - Arrays, Pre-Biased |
| Series： | - |
| Packaging ： | Tape & Reel (TR) |
| Transistor Type： | 2 NPN - Pre-Biased (Dual) |
| Current - Collector (Ic) (Max)： | 100mA |
| Voltage - Collector Emitter Breakdown (Max)： | 50V |
| Resistor - Base (R1) (Ohms)： | 47k |
| Resistor - Emitter Base (R2) (Ohms)： | 22k |
| DC Current Gain (hFE) (Min) @ Ic, Vce： | 80 @ 5mA, 10V |
| Vce Saturation (Max) @ Ib, Ic： | 250mV @ 5mA, 10mA |
| Current - Collector Cutoff (Max)： | 500nA |
| Frequency - Transition： | - |
| Power - Max： | 500mW |
| Mounting Type： | Surface Mount |
| Package / Case： | SOT-563, SOT-666 |
| Supplier Device Package： | SOT-563 |
