ON Semiconductor
NTMFS4847NAT1G的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | MOSFET |
| RoHS： | Yes |
| Brand： | ON Semiconductor |
| Transistor Polarity： | N-Channel |
| Vds - Drain-Source Breakdown Voltage： | 30 V |
| Vgs - Gate-Source Breakdown Voltage： | 16 V |
| Id - Continuous Drain Current： | 85 A |
| Rds On - Drain-Source Resistance： | 4.1 mOhms |
| Configuration： | Single |
| Vgs th - Gate-Source Threshold Voltage： | 1.8 V |
| Qg - Gate Charge： | 19.2 nC |
| Maximum Operating Temperature： | + 150 C |
| Pd - Power Dissipation： | 48.1 W |
| Mounting Style： | SMD/SMT |
| Package / Case： | SO-8FL |
| Packaging： | Reel |
| Forward Transconductance - Min： | 74 S |
| Minimum Operating Temperature： | - 55 C |
| Factory Pack Quantity： | 1500 |
NTMFS4847NAT1G相关文档
- Application Note: Description of the ON Semiconductor MOSFET Model
- Simulation Model: PSpice Model
- Application Note: Board Mounting Notes for SO-8 Flat Lead
- Simulation Model: Saber Model
- Package Drawing: DFN5 (SO-8FL) 5x6, 1.27P
- Simulation Model: Spice2 Model
- Simulation Model: Spice3 Model
