Texas Instruments
OPA627AP的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | High Speed Operational Amplifiers |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Product： | Current Feedback Amplifier |
| Number of Channels： | 1 Channel |
| Voltage Gain dB： | 116 dB |
| Input Offset Voltage： | 0.5 mV |
| Slew Rate： | 55 V/us |
| Operating Supply Voltage： | 36 V |
| Supply Current： | 7.5 mA |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | Through Hole |
| Package / Case： | PDIP-8 |
| Packaging： | Tube |
| Common Mode Rejection Ratio - Min： | 100 dB |
| Gain Bandwidth Product： | 16 MHz |
| Maximum Power Dissipation： | 1000 mW |
| Minimum Operating Temperature： | - 25 C |
| Series： | OPA627 |
| Factory Pack Quantity： | 50 |
| Supply Voltage - Max： | +/- 18 V |
| Supply Voltage - Min： | +/- 4.5 V |
OPA627AP相关文档
- SPICE Model: OPA627 TINA-TI Spice Model
- TINA Reference Design: OPA627 TINA-TI Reference Design (Rev. A)
- SPICE Model: OPA627 PSpice Model
OPA627AP应用笔记
- Noise Analysis for High Speed Op Amps (Rev. A)
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Comparison of Noise Performance of FET Transimpedence Amp/Switched Integrator
- Compensate Transimpedance Amplifiers Intuitively (Rev. A)
- Single-Supply Operation of Operational Amplifiers
- Digitally Programmable, Time-Continuous Active Filter
- Fast Settling Low-Pass Filter
- Improved Device Noise Performance For the 3650 Isolation Amplifier
- Tuning in Amplifiers
- Composite Op Amp Gives You The Best of Both Worlds
- Op Amp Performance Analysis
- OPA627, OPA637 EMI Immunity Performance (Rev. A)
