PLASTIC-ENCAPSULATE TRANSISTORS
S8050LT1
S8050LT1
TRANSISTORNPN
SOT23
FEATURES
Power dissipation
PCM
Collector current
ICM
:
0.3
0.5
WTamb=25℃)
1. BASE
:
A
V
2. EMITTER
3. COLLECTOR
Collector-base voltage
V(BR)CBO : 40
ELECTRICAL CHARACTERISTICSTamb=25unless otherwise specified)
Parameter
Symbol
V(BR)CBO
V(BR)CEO
V(BR)EBO
ICBO
Test conditions
Ic= 100μAIE=0
Ic= 0.1mAIB=0
IE=100μAIC=0
VCB=40 V , IE=0
VCB=20V , IE=0
MIN
40
25
5
TYP
MAX
UNIT
V
Collector-base breakdown voltage
Collector-emitter breakdown voltage
Emitter-base breakdown voltage
Collector cut-off current
V
V
0.1
0.1
μA
μA
μA
Collector cut-off current
ICEO
Emitter cut-off current
IEBO
VEB= 5V ,
IC=0
0.1
HFE(1)
VCE=1V, IC= 50mA
VCE=1V, IC= 500mA
IC=500 mA, IB= 50mA
IC=500 mA, IB= 50mA
IE= 100mA
120
50
350
DC current gain(note)
HFE(2)
Collector-emitter saturation voltage
Base-emitter saturation voltage
Base-emitter voltage
VCE(sat)
VCE(sat)
VBE
0.6
V
V
1.2
1.4
VCE=6V, IC= 20mA
f=30MHz
Transition frequency
150
MHz
fT
CLASSIFICATION OF HFE(1)
Rank
L
H
Range
100-200
200-350
DEVICE MARKING : S8050LT1=J3Y
Wing Shing Computer Components Co., (H.K.)Ltd.
Tel:(852)2341 9276 Fax:(852)2797 8153
E-mail: wsccltd@hkstar.com
