SG3525ADWR2G的详细信息

Manufacturer: ON Semiconductor
Product Category: Switching Controllers
RoHS: Yes
Brand: ON Semiconductor
Topology: Half-Bridge, Push-Pull
Number of Outputs: 2
Switching Frequency: 400 kHz
Duty Cycle - Max: 49 %
Output Current: 400 mA
Maximum Operating Temperature: + 70 C
Mounting Style: SMD/SMT
Package / Case: SOIC-16 Wide
Packaging: Reel
Fall Time: 50 ns
Minimum Operating Temperature: 0 C
Rise Time: 100 ns
Series: SG3525A
Factory Pack Quantity: 1000
Synchronous Pin: Yes
SG3525A
PulseWidthModulator
ControlCircuit
The SG3525A pulse width modulator control circuit offers
improved performance and lower external parts count when
implemented for controlling all types of switching power supplies.
The on−chip +5.1 V reference is trimmed to "1% and the error
amplifier has an input common−mode voltage range that includes the
reference voltage, thus eliminating the need for external divider
resistors. A sync input to the oscillator enables multiple units to be
slaved or a single unit to be synchronized to an external system clock.
A wide range of deadtime can be programmed by a single resistor
16
PDIP−16
N SUFFIX
CASE 648
1
SG3525AN
AWLYYWW
connected between the C and Discharge pins. This device also
T
features built−in soft−start circuitry, requiring only an external timing
capacitor. A shutdown pin controls both the soft−start circuitry and the
output stages, providing instantaneous turn off through the PWM latch
with pulsed shutdown, as well as soft−start recycle with longer
shutdown commands. The under voltage lockout inhibits the outputs
16
1
16
and the changing of the soft−start capacitor when V
is below
CC
SOIC−16L
DW SUFFIX
CASE 751G
16
SG3525A
AWLYYWW
nominal. The output stages are totem−pole design capable of sinking
and sourcing in excess of 200 mA. The output stage of the SG3525A
features NOR logic resulting in a low output for an off−state.
1
1
Features
A
= Assembly Location
8.0 V to 35 V Operation
WL = Wafer Lot
YY = Year
WW = Work Week
5.1 V " 1.0% Trimmed Reference
100 Hz to 400 kHz Oscillator Range
Separate Oscillator Sync Pin
Adjustable Deadtime Control
Input Undervoltage Lockout
PIN CONNECTIONS
Latching PWM to Prevent Multiple Pulses
Pulse−by−Pulse Shutdown
Dual Source/Sink Outputs: "400 mA Peak
Pb−Free Packages are Available*
Inv.Input
Noninv.Input
Sync
V
V
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
ref
CC
OutputB
OSC.Output
V
C
C
T
Ground
R
T
OutputA
Discharge
Soft−Start
Shutdown
Compensation
(TopView)
ORDERING INFORMATION
*For additional information on our Pb−Free strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
Semiconductor Components Industries, LLC, 2005
1
Publication Order Number:
January, 2005 − Rev. 5
SG3525A/D
