型号: SG3525AN
厂商: STMicroelectronics STMicroelectronics
标准:
分类: 半导体集成电路 - IC
描述: switching controllers voltage mode w/sync
PDF: 预览
报错 收藏

SG3525AN的详细信息

Manufacturer: STMicroelectronics
Product Category: Switching Controllers
RoHS: Yes
Brand: STMicroelectronics
Number of Outputs: 2
Switching Frequency: 500 kHz
Duty Cycle - Max: 49 %
Output Voltage: 5.2 V
Mounting Style: Through Hole
Package / Case: PDIP-16
Packaging: Tube
Series: SG3525
Factory Pack Quantity: 25
SG2525A
SG3525A
®
REGULATING PULSE WIDTH MODULATORS
.
.
.
.
.
.
.
.
8 TO 35 V OPERATION
5.1 V REFERENCE TRIMMED TO ± 1 %
100 Hz TO 500 KHz OSCILLATOR RANGE
SEPARATE OSCILLATOR SYNC TERMINAL
ADJUSTABLE DEADTIME CONTROL
INTERNAL SOFT-START
PULSE-BY-PULSE SHUTDOWN
INPUT UNDERVOLTAGE LOCKOUT WITH
HYSTERESIS
DIP16
16(Narrow)
.
LATCHING PWM TO PREVENT MULTIPLE
PULSES
DUAL SOURCE/SINK OUTPUT DRIVERS
.
DESCRIPTION
The SG3525A series of pulse width modulator inte-
grated circuits are designed to offer improved per-
formance and lowered external parts count when
used in designing all types of switching power sup-
plies. The on-chip + 5.1 V reference is trimmed to ±
1 % and the input common-mode range of the error
amplifier includes the reference voltage eliminating
external resistors. A sync input to the oscillator al-
lows multiple units to be slaved or a single unit to be
synchronized to an external system clock. A single
resistor between the CT and the discharge terminals
provide a wide range of dead time ad- justment.
These devices also feature built-insoft-startcircuitry
with only an external timing capacitor required. A
shutdown terminal controls both the soft-start circu-
ity and the output stages, providing instantaneous
turn off through the PWM latch with pulsed shut-
down, as well as soft-start recycle with longer shut-
down commands. These functions are also control-
led by an undervoltage lockout which keeps the out-
puts off and the soft-start capacitor discharged for
sub-normal input voltages. This lockout circuitry in-
cludes approximately 500 mV of hysteresis for jitter-
free operation. Another feature of these PWM cir-
cuits is a latch following the comparator. Once a
PWM pulses has been terminated for any reason,
the outputs will remain off for the duration of the pe-
riod. The latch is reset with each clock pulse. The
output stages are totem-pole designs capable of
sourcing or sinking in excess of 200 mA. The
SG3525A output stage features NOR logic, giving a
LOW output for an OFF state.
PIN CONNECTIONS AND ORDERING NUMBERS
(top view)
Type
Plastic DIP
SG2525AN
SG3525AN
SO16
SG2525A
SG3525A
SG2525AP
SG3525AP
June 2000
1/12
