Image SP485EEN-L/TR
型号: SP485EEN-L/TR
厂商: Exar Corporation Exar Corporation
标准:
分类: 半导体集成电路 - IC
描述: RS-485 interface IC low pwr half-duplex RS-485
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

SP485EEN-L/TR的详细信息

Manufacturer: Exar
Product Category: RS-485 Interface IC
RoHS: Yes
Brand: Exar
Function: Transceivers
Number of Drivers: 1
Number of Receivers: 1
Data Rate: 10 Mbps
Operating Supply Voltage: 5 V
Supply Current: 900 uA
Operating Temperature Range: - 40 C to + 85 C
Mounting Style: SMD/SMT
Package / Case: SOIC-8
Duplex: Half Duplex
Maximum Operating Temperature: + 85 C
Maximum Power Dissipation: 550 mW
Minimum Operating Temperature: - 40 C
Output Type: Differential
Packaging: Reel
Series: SP481E / SP485E
Shutdown: Yes
Factory Pack Quantity: 2500
SP481E / SP485E
Enhanced Low Power Half-Duplex
RS-485 Transceivers
• +5V Only
• Low Power BiCMOS
• Driver / Receiver Enable for Multi-Drop
configurations
• Low Power Shutdown mode (SP481E)
• Enhanced ESD Specifications:
+/-ꢀ5kV Human Body Model
+/-15kV IEC61000-4-2 Air Discharge
• Available in RoHS Compliant, Lead Free
Packaging.
DESCRIPTION
The SP481E and SP485E are a family of half-duplex transceivers that meet the specifications
of RS-485 and RS-422 serial protocols with enhanced ESD performance. The ESD toler-
ance has been improved on these devices to over +ꢀ5kV for both Human Body Model and
IEC61000-4-2 Air Discharge Method. These devices are pin-to-pin compatible with Exar's
SP481 and SP485 devices as well as popular industry standards. As with the original ver-
sions, the SP481E and SP485E feature Exar's BiCMOS design allowing low power opera-
tion without sacrificing performance. The SP481E and SP485E meet the requirements of
the RS-485 and RS-422 protocols up to 10Mbps under load. The SP481E is equipped with
a low power shutdown mode.
Exar Corporation 48720 Kato Road, Fremont CA, 94538 • 5ꢀ0-668-70ꢀ7 • www.exar.com
SP48ꢀE,485E_ꢀ04_0524ꢀ3
