Image SPX1117M3-L-3-3/TR
型号: SPX1117M3-L-3-3/TR
厂商: Exar Corporation Exar Corporation
标准:
分类: 半导体集成电路 - IC
描述: ldo voltage regulators 800malow dropout
PDF: 预览
报错 收藏

SPX1117M3-L-3-3/TR的详细信息

Manufacturer: Exar
Product Category: LDO Voltage Regulators
RoHS: Yes
Brand: Exar
Input Voltage MAX: 15 V
Output Voltage: 3.3 V
Dropout Voltage - Max: 1.3 V
Output Current: 800 mA
Load Regulation: 0.2 %
Number of Outputs: 1 Output
Output Type: Fixed
Maximum Operating Temperature: + 125 C
Mounting Style: SMD/SMT
Package / Case: SOT-223
Input Voltage MIN: 2.6 V
Line Regulation: 0.1 %
Minimum Operating Temperature: - 40 C
Packaging: Reel
PSRR / Ripple Rejection - Typ: 75 dB at 120 Hz
Factory Pack Quantity: 2500
Voltage Regulation Accuracy: 0.1 %
SPX1117
800mA Low Dropout Voltage Regulator
August 2010
Rev. 2.1.0
GENERAL DESCRIPTION
APPLICATIONS
The SPX1117 is a low power positive-voltage
regulator designed to satisfy moderate power
requirements with a cost effective, small
footprint solution.
Desktop PC Servers
Graphic/Video Cards
Industrial Equipments
Power Supplies
This device is an excellent choice for use in
battery-powered applications and portable
computers. The SPX1117 features very low
quiescent current and a low dropout voltage of
1.1V at a full load. As output current
decreases, quiescent current flows into the
load, increasing efficiency. SPX1117 is
available in adjustable or fixed 1.5V, 1.8V,
2.5V, 3.3V and 5V output voltages.
FEATURES
Guaranteed 800mA Output Current
Guaranteed 1A Peak Current
Three Terminal Adjustable or Fixed
1.5V, 1.8V, 2.5V, 3.3V and 5V
The SPX1117 is offered in 3-pin SOT-223 and
TO-263 surface mount packages.
Low Quiescent Current
Low Dropout Voltage of 1.1V at 800mA
0.1% Line and 0.2% Load Regulation
Stable with 2.2µF Ceramic Capacitor
Overcurrent and Thermal Protection
An output capacitor of 10µF provides
unconditional stability while a smaller 2.2µF
capacitor is sufficient for most applications.
Lead Free, RoHS Compliant Packages
SOT223 and TO263
FUNCTIONAL DIAGRAM
Fig. 1: SPX1117 Application Diagram
