型号: SS14
厂商: Fairchild Semiconductor Fairchild Semiconductor
标准:
分类: 半导体分离式半导体
描述: schottky diodes & rectifiers sma 40v 1.0A
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 第三方平台下载 >>

SS14的详细信息

Manufacturer: Fairchild Semiconductor
Product Category: Schottky Diodes & Rectifiers
RoHS: Yes
Product: Schottky Rectifiers
Peak Reverse Voltage: 40 V
Forward Continuous Current: 1 A
Max Surge Current: 40 A
Configuration: Single
Forward Voltage Drop: 0.5 V
Maximum Reverse Leakage Current: 200 uA
Operating Temperature Range: - 65 C to + 125 C
Mounting Style: SMD/SMT
Package / Case: SMA (DO-214AC)
Packaging: Reel
Brand: Fairchild Semiconductor
Series: SS14
Factory Pack Quantity: 7500
Part # Aliases: SS14_NL
Unit Weight: 106 mg
October 2013
SS12 - S100
Schottky Rectifier
Description
Features
• Glass-Passivated Junctions
The SS12-S100 series includes high-efficiency, low
power loss, general-propose Schottky rectifiers. The clip
-bonded leg structure provides high thermal performance
and low electrical resistance. These rectifiers are suited
for free wheeling, secondary rectification, and reverse
polarity protection applications.
• High-Current Capability, Low V
F
Applications
• Low Voltage
• High-Frequency Inverters
• Free Wheeling
• Polarity Protection
SMA/DO-214AC
COLOR BAND DENOTES CATHODE
OrderingInformation
Part Number
SS12
Marking
SS12
SS13
SS14
SS15
SS16
SS18
SS19
S100
Package
Packing Method
SS13
SS14
SS15
DO-214AC
Tape and Reel
SS16
SS18
SS19
S100
Absolute Maximum Ratings
Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be opera-
ble above the recommended operating conditions and stressing the parts to these levels is not recommended. In addi-
tion, extended exposure to stresses above the recommended operating conditions may affect device reliability. The
absolute maximum ratings are stress ratings only. Values are at T = 25°C unless otherwise noted.
A
Value
Symbol
Parameter
Units
SS12 SS13 SS14 SS15 SS16 SS18 SS19 S100
Maximum Repetitive Reverse
Voltage
V
20 30 40 50 60 80 90 100
V
A
RRM
Maximum Average Forward Current:
I
1.0
40
F(AV)
0.375-inch Lead Length at T = 75°C
A
Non-Repetitive Peak Forward Surge
Current: 8.3 ms Single Half-Sine
Wave
I
A
FSM
T
Storage Temperature Range
-65 to +150
-65 to +125
°C
°C
STG
T
Operating Junction Temperature
J
© 2001 Fairchild Semiconductor Corporation
SS12 - S100 Rev. 1.1.2
www.fairchildsemi.com
1
