型号: STM32F103ZFH6TR
厂商: STMicroelectronics STMicroelectronics
标准:
分类: 半导体集成电路 - IC
描述: arm microcontrollers - mcu stm32f103 perf line M3 768kb 72 mhz mcu
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

STM32F103ZFH6TR的详细信息

Manufacturer: STMicroelectronics
Product Category: ARM Microcontrollers - MCU
Brand: STMicroelectronics
Core: ARM Cortex M3
Data Bus Width: 32 bit
Maximum Clock Frequency: 72 MHz
Program Memory Size: 768 kB
Data RAM Size: 96 kB
Operating Supply Voltage: 2 V to 3.6 V
Maximum Operating Temperature: + 85 C
Package / Case: BGA-144
Mounting Style: SMD/SMT
Data RAM Type: SRAM
Minimum Operating Temperature: - 40 C
Packaging: Reel
Processor Series: ARM Cortex
Program Memory Type: Flash
Series: STM32F103ZF
Factory Pack Quantity: 1500
STM32F103xF
STM32F103xG
XL-density performance line ARM-based 32-bit MCU with 768 KB to
1 MB Flash, USB, CAN, 17 timers, 3 ADCs, 13 communication interfaces
Target specification
Features
FBGA
Core: ARM 32-bit Cortex™-M3 CPU with MPU
LQFP64 10 × 10 mm,
LQFP100 14 × 14 mm,
– 72 MHz maximum frequency,
LFBGA144 10 × 10 mm
1.25 DMIPS/MHz (Dhrystone 2.1)
performance at 0 wait state memory
access
LQFP144 20 × 20 mm
Up to 112 fast I/O ports
– 51/80/112 I/Os, all mappable on 16
external interrupt vectors and almost all
5 V-tolerant
– Single-cycle multiplication and hardware
division
Memories
Up to 17 timers
– 768 Kbytes to 1 Mbyte of Flash memory
– 96 Kbytes of SRAM
– Flexible static memory controller with 4
Chip Select. Supports Compact Flash,
SRAM, PSRAM, NOR and NAND memories
– Up to ten 16-bit timers, each with up to 4
IC/OC/PWM or pulse counter and
quadrature (incremental) encoder input
– 2 × 16-bit motor control PWM timers with
dead-time generation and emergency stop
– LCD parallel interface, 8080/6800 modes
– 2 × watchdog timers (Independent and
Window)
Clock, reset and supply management
– SysTick timer: a 24-bit downcounter
– 2 × 16-bit basic timers to drive the DAC
– 2.0 to 3.6 V application supply and I/Os
– POR, PDR, and programmable voltage
detector (PVD)
Up to 13 communication interfaces
2
– 4-to-16 MHz crystal oscillator
– Up to 2 × I C interfaces (SMBus/PMBus)
– Internal 8 MHz factory-trimmed RC
– Internal 40 kHz RC with calibration
– 32 kHz oscillator for RTC with calibration
– Up to 5 USARTs (ISO 7816 interface, LIN,
IrDA capability, modem control)
– Up to 3 SPIs (18 Mbit/s), 2 with I S
interface multiplexed
– CAN interface (2.0B Active)
– USB 2.0 full speed interface
– SDIO interface
2
Low power
– Sleep, Stop and Standby modes
– V
supply for RTC and backup registers
BAT
3 × 12-bit, 1 µs A/D converters (up to 21
CRC calculation unit, 96-bit unique ID
channels)
®
ECOPACK packages
– Conversion range: 0 to 3.6 V
Triple-sample and hold capability
Temperature sensor
Table 1.
Device summary
Part number
Reference
2 × 12-bit D/A converters
STM32F103RF STM32F103VF
STM32F103ZF
DMA: 12-channel DMA controller
STM32F103xF
STM32F103xG
– Supported peripherals: timers, ADCs, DAC,
2
2
SDIO, I Ss, SPIs, I Cs and USARTs
STM32F103RG STM32F103VG
STM32F103ZG
Debug mode
– Serial wire debug (SWD) & JTAG interfaces
– Cortex-M3 Embedded Trace Macrocell™
January 2012
Doc ID 16554 Rev 3
1/120
This is preliminary information on a new product foreseen to be developed. Details are subject to change without notice.
1
