Image STM32L051C8T6
型号: STM32L051C8T6
厂商: STMicroelectronics STMicroelectronics
标准:
分类: 半导体集成电路 - IC
描述: arm microcontrollers - mcu
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

STM32L051C8T6的详细信息

Manufacturer: STMicroelectronics
Product Category: ARM Microcontrollers - MCU
Core: ARM Cortex M0+
Data Bus Width: 32 bit
Maximum Clock Frequency: 32 MHz
Program Memory Size: 64 kB
Data RAM Size: 8 kB
On-Chip ADC: Yes
Operating Supply Voltage: 1.8 V to 3.6 V
Maximum Operating Temperature: + 85 C
Package / Case: LQFP-48
Mounting Style: SMD/SMT
A/D Bit Size: 12 bit
A/D Channels Available: 10
Brand: STMicroelectronics
Data RAM Type: SRAM
Data ROM Size: 2 kB
Data ROM Type: EEPROM
Interface Type: I2C, LPUART, SPI, USART
Minimum Operating Temperature: - 40 C
Number of Programmable I/Os: 37
Number of Timers: 5
On-Chip DAC: No
Program Memory Type: Flash
STM32L051x6 STM32L051x8
Access line ultra-low-power 32-bit MCU ARM®-based
Cortex®-M0+, up to 64 KB Flash, 8 KB SRAM, 2 KB EEPROM, ADC
Datasheet - production data
Features
&"'!
Ultra-low-power platform
1.65 V to 3.6 V power supply
LQFP32 7x7 mm
LQFP48 7x7 mm
LQFP64 10x10 mm
WLCSP36
UFQFPN32
5x5 mm
TFBGA64
5x5mm
-40 to 125 °C temperature range
0.27 µA Standby mode (2 wakeup pins)
0.4 µA Stop mode (16 wakeup lines)
0.8 µA Stop mode + RTC + 8 KB RAM retention
139 µA/MHz Run mode at 32 MHz
3.5 µs wakeup time (from RAM)
Rich Analog peripherals (down to 1.8 V)
12-bit ADC 1.14 Msps up to 16 channels (down
to 1.65 V)
2x ultra-low-power comparators (window mode
and wake up capability, down to 1.8 V)
5 µs wakeup time (from Flash)
®
®
7-channel DMA controller, supporting ADC, SPI,
I2C, USART, Timers
Core: ARM 32-bit Cortex -M0+ with MPU
From 32 kHz up to 32 MHz max.
0.95 DMIPS/MHz
7x peripherals communication interface
2x USART (ISO 7816, IrDA) 1x UART (low power)
2x SPI 16 Mbits/s
Reset and supply management
Ultra-safe, low-power BOR (brownout reset)
with 5 selectable thresholds
Ultralow power POR/PDR
Programmable voltage detector (PVD)
2x I2C (SMBus/PMBus)
9x timers: 1x 16-bit with up to 4 channels, 2x 16-bit
with up to 2 channels, 1x 16-bit ultra-low-power
timer, 1x SysTick, 1x RTC, 1x 16-bit basic, and 2x
watchdogs (independent/window)
Clock sources
1 to 25 MHz crystal oscillator
32 kHz oscillator for RTC with calibration
High speed internal 16 MHz factory-trimmed RC
(+/- 1%)
CRC calculation unit, 96-bit unique ID
®
All packages are ECOPACK 2
Internal low-power 37 kHz RC
Internal multispeed low-power 65 kHz to
4.2 MHz RC
Table 1. Device summary
Reference
Part number
PLL for CPU clock
STM32L051C6
STM32L051K6
STM32L051R6
Pre-programmed bootloader
USART, SPI supported
Development support
Serial wire debug supported
STM32L051x6
STM32L051T6
STM32L051C8
STM32L051K8
STM32L051R8
STM32L051x8
Up to 51 fast I/Os (45 I/Os 5V tolerant)
Memories
STM32L051T8
Up to 64 KB Flash with ECC
8 KB RAM
2 KB of data EEPROM with ECC
20-byte backup register
Sector protection against R/W operation
June 2014
DocID025938 Rev 3
1/120
This is information on a product in full production.
